| Place of Origin: | China |
|---|---|
| Brand Name: | BOTO |
| Certification: | CE |
| Model Number: | BT-1800Muffle |
| Minimum Order Quantity: | 1 SET |
| Price: | 3200USD |
| Packaging Details: | Export carton |
| Delivery Time: | 25 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 30 Set/month |
| Product Name: | Lab Muffle Furnace | Heating Element Type:: | Silicon Carbide (SiC) |
|---|---|---|---|
| Heating Rate:: | < 15°C (59°F) / Min | Test Accuracy: | ±1% |
| Temperature Optional: | 1000°C, 1100°C, 1200°C, 1400°C, 1600°C, 1700°C,1800°C | Size Optional: 1L, 2L, 4L, 5L, 8L, 10L, 20L: | 1L, 2L, 4L, 5L, 8L, 10L, 20L |
| Material: | SUS304, #SUS 304 Stainless Steel | Temperature Control: 40 Programmable Segments For Precise Control: | 40 Programmable Segments For Precise Control |
| High Light: | 1100C high temperature muffle furnace,rohs 20L high temperature muffle furnace,rohs sus304 20L vacuum muffle furnace |
||
BOTO-1800Muffle muffle furnaces feature a chamber with Mitsubishi (Japan) high quality grade 1900 alumina fiber insulation and the famous molybdenum silicide (MoSi2) heating elements. A dual-wall steel housing helps minimize heat loss to exterior surface.
Furnace operation is controlled by Shimaden (Japan) 40-segment digital controller with built-in RS485 digital communications port and USB adaptor, allowing the user to connect to a PC for remote control and monitoring of the furnace. You can also save or export test results.
Features
1 Microprocessor based self-tuning PID control provides optimum thermal process with minimal overshoot.
2 Built-in ammeter and dual voltmeters for easy monitoring and troubleshooting.
3 Built-in computer interface.
4 Long life type B thermocouple.
5 CE compliant
Function and performance index
| Chamber vs usable size (DxWxH) | 7 x 6 x 6" (0.15 cubic foot) / 5 x 5 x 5.5" |
| Max. working temperature | 1800°C (3272°F) for less than 5 hours |
| Refractory lining | Mitsubishi (Japan) high quality grade 1900 fiber alumina |
| Heating element | Kan-thal (Sweden) grade 1900 Molybdenum Silicide (MoSi2), 6 installed |
| Thermocouple type | B or PtRh40-PtRh20 (optional) |
| Min. working temperature | 300°C (572°F) |
| Max. constant working temperature | 1700°C (3092°F) or 1750°C with PtRh40-PtRh20 (optional) |
| Temperature controller | Shimaden fp93 (Japan) with 4 programs and 40 segments (ie. 4 x 10 segments or 2 x 20 segments) Eurotherm temperature controller (optional) |
| Max heating / cooling rate | 1200°C and below: <30°C/min, 1200°C+: < 15°C/min |
| Temperature accuracy | +/- 1°C |
| Input | 208-240v AC, 50/60Hz, single phase |
| Maximum output | 4.5 kW |
| Unit/shipping dimensions (WxDxH) | 24 x 22 x 34" / 30 x 29 x 42" |
| Shipping weight | 300 Lb |
| CE compliance | Yes |
BOTO Testing equipment Technology Co., Ltd is a high technology supported production-oriented enterprise who specializes in developing, manufacturing, marketing all kinds of environmental equipment. Our company has advanced technology, experienced technical management personnel and efficient professional service staffs, fine quality management and perfect after-sales service system.
Our company mainly produce simulated environmental tester, plastic and rubber tester etc. on all kinds of materials testing industries. The production base is located in the country’s manufacturing center Dongguan, Guangdong province, China. In order to service our customers better in terms of reducing costs and early delivery, in 2005 we had set up an office in Kunshan, Jiangsu province for Eastern China marketing and servicing.
BOTO deals with customers from more than 150 countries and regions. Meanwhile, we are committed to cooperate with different dealers in different countries and regions in order to offer better service. Our mission is to help every customers establish testing labs to ensure the quality of their products.
Our company will continue to develop, innovate and keep faith. We combine with the international testing standards and the specific demands of customers that may establish a new banner in Chinese testing industry.
Our Services
During the whole business process, we offer Consultative Selling service.
1) Customer inquiry process:
Discussing testing requirements and technical details, suggested suitable products to customer to confirm. Then quote most suitable price according to customer requirements.
2) Specifications customize process:
Drawing related drawings to confirm with customer for customized requirements. Offer reference photos to show the products appearance. Then, confirm the final solution and confirm final price with customer.
3) Production and delivery process:
We will produce the machines according to confirmed PO requirements. Offering photos to show production process.
After finish production, offer photos to customer to confirm again with the machine. Then do own factory calibration or third party calibration(as customer requirements). Check and test all the details and then arrange packing.
Deliver the products in confirmed shipping time and inform customer.
4) Installation and after sale service:
Defines installing those products in the field and providing after-sales support.
