Solar Panel UV Aging Test Chamber Wave Length 320-400mm Computer Control

China Solar Panel UV Aging Test Chamber Wave Length 320-400mm Computer Control supplier
Solar Panel UV Aging Test Chamber Wave Length 320-400mm Computer Control supplier Solar Panel UV Aging Test Chamber Wave Length 320-400mm Computer Control supplier Solar Panel UV Aging Test Chamber Wave Length 320-400mm Computer Control supplier Solar Panel UV Aging Test Chamber Wave Length 320-400mm Computer Control supplier

Large Image :  Solar Panel UV Aging Test Chamber Wave Length 320-400mm Computer Control

Product Details:

Place of Origin: CHINA
Brand Name: HST
Certification: CE ISO FCC
Model Number: HST-UV-

Payment & Shipping Terms:

Minimum Order Quantity: 1 SET
Price: Negotiable
Packaging Details: Standard Export Wooden Package
Delivery Time: 7-20 days
Payment Terms: T/T, Western Union
Supply Ability: 500 sets/month
Contact Now
Detailed Product Description
Control: Computer Control Sample Shelf Size: 500*480mm
Temperature Range: TR+5ºC ~ 70ºC Wave Length: 320-400mm
Distance Between Lamps: 70mm Life Span: ≥1500h

320-400mm Computer Control Weather Resistance Solar Panel UV Aging Test Chamber

Product Description:

 standard technical specification:
Model NO. Accelerated UV-A exposure UV Resistance Ageing Chamber
Inner chamber size(W*H*D) 500*500*600mm
External chamber size(W*H*D) 700*850*1300mm
Temp. range TR+5ºC ~ 70ºC
Temp. fluctuation ±3ºC
Humidity range 80%TH~98%RH
Sample shelf size 500*480mm (adjustable)
Black board temp. display range +30ºC ~ +70ºC
Black board temp. fluctuation ±1ºC
Distance between vertical product and lamp 50mm ±2mm
Distance between lamps 70mm
Uniform working area 400*400mm
Other components Equipped with sprinklet device and Irrandiation meter for testing UV radiant intensity.

UV lamp parameters
Model UV-A
Wave length 320-400mm
Power 300W
Length 700mm
Quantity 4pcs
Life span ≥1500h
Brand Philips


Control system
1. High precision temperature control instrument
2. Programmable time controller (set test time, illumination time, condensation time, spraying time )
3. Electronic components: Adopt product of national joint venture company
4. Main configuraton: Temperature controller , time controller, illumination time accumulator, digital displayed ampere meter, inflow magnetic valve, UV lamp.

Structure and material
1. Working room, smaple shelf, liner and shell are made from SUS#304, automatic control for inflow.
2. Stainless steel heater is equipped with water-break protection device. It can automatically cut off the power in the humidifying system in the case of water shortage, the finned air heating tube is made of stainless steel materials, the over temperature protection device is installed in the vabinet, can effectively guarrantee test.

Test standard
This UV test chamber meets GB/T14522-93, Q/CS01-92 standard. It can meet GB/T14522-93 the method that mechanical products be acceletated tested in a artificial way with plastic, [aint, rubber meterial, GB/T2424.14-1995 basic environmental testing procedures of electrical and electronic products, American material test institute ASTMG53-84 test method that non-metallic materials exposed to fluorescent UV condensation.



Customer visit:

Solar Panel UV Aging Test Chamber Wave Length 320-400mm Computer Control




After-sales service
1. Free parts for 12 months.
2. One year warranty, during in this year, we provide free maintenance. Beyong the warranty, we provide accessories with low cost, lifetime maintenance service is available.
