Blue Purple 4 Layers Aging Test Chamber , Programmable High And Low Temperature Test Chamber
Detailed Product Description
||AC 1 Phase 220V, 3 Phase 380V
|Heat Up Time:
||Cooling Down Time:
Blue purple 4 Layers Programmable High Low Temperature Aging Test Chamber
High Low temperature aging test chamber is applied to test the capabilities of heat-resistance, cold-resistance, dry-resistance and moisture-resistance of materials. It is mainly used in testing the adaptability of electronics, electrical appliances, food, automobile, rubber and plastic, metal and other products, parts and materials in the high and low temperature and humid environment when storage, transport and using.
|Humidity Range||30%HR ~95%HR|
|Heat-up Time( min.)||30|
|Pull-down Time( min.)||40|
|Material||Exterior||Stainless steel piate+Powder Coated|
|Interior||SUS#304 stainless steel piate|
|Insulation||PU & Fiberglass wool|
|Heating||SUS#304 stainless steel high-speed heater|
|Humidifying||Surface evaporating system|
|Cooling||Airtight compressor+vaporator fins+air-cooling condenser|
|ehumidifying||ADP Critical dewpoint cooling/dehumidifying method|
|Controller||Digital electronic indicators+S.S.R.With PID automatic calculation capabilty|
|Other Components||Vacuum glass inspection windown,50mm cable port, control status indicator lights,|
chamber lamp, 2 pcs, adjustable loading shelves
|Sevey Devices||Overheating prevention circuit-breaker,compressor overload protectin,control system overload protection,humidifying|
system overheading drying out prevention,breakdown indicator light
|Power Source[K.W.]||AC 1Ψ 220V, 3 phase 380V 60/50Hz|
1. The inner body of the chamber is made of SUS304 stainless steel plate while the outer housing is made of A3 steel plate sprayed with plastic. Moreover the chamber door adopts refined silicone rubber seal.
2. Accurate temperature and humidity test chamber has a separate humidifier circuit from electric circuit improves safety and protects the circuit against the leakage of water supply line.
3. It has a LCD touch screen, easy operation and program.
4. It's Able to display the relative date and information of the whole operating system in running mode, graphic display.
5. Precautions, maintenance and troubleshooting appear on the screen instantly. The fan motor provides greater cyclic airflow to avoid dead corner in the chamber so as to obtain a uniform distribution of temperature and humidity.
6. The system of heating up, heating down, dehumidifying, and humidifying can be operated independently so as to reduce the cost of testing, extend the operating life of the machine and decrease the failure rate.
7. Water Supply adopts automatic watering System, Circulating water supply together with water filter.
