110V Chocolate Sus304 Industrial Conveyor Metal Detector Food Processing

Basic Information
Place of Origin: CHINA
Brand Name: BOTO
Certification: CE ISO
Model Number: BT1503
Minimum Order Quantity: 1 SET
Price: Negotiation
Packaging Details: PLY-WOODEN CASE
Payment Terms: D/A, D/P, T/T, Western Union, L/C
Supply Ability: 100000Set/month
Detection Depth:: Different ,as Detail Pages Showing Sensitivity:: Fe,no-Fe,sus304 Different
Weight:: 3-30kg(pls Note Your Prpduct Weight ) Power Supply:: 380/220/110V 50/60Hz 200w
Display:: LCD Screen Customized Support:: OEM, ODM
Transfer Speed:: 40 Meter / Mins Model:: BOTO-220/300(Different Size ,pls Note Your Product Size)
Metal Detector Power:: 100-265VAC, 50-60Hz Metal Detector Model:: Food Production Line Metal Detector
High Light:

110V Chocolate metal detector food processing

,

sus304 metal detector food processing

,

sus304 industrial metal detector conveyor

Belt Conveyor Metal Detector for Chocolate Industrial Metal Detectors

Application:

Transmission type all-digital metal detection machine is a new generation of microcomputer intelligent metal detection equipment launched by the company. The product has high sensitivity and stable performance. Besides, it breaks through the technical bottleneck that most of the equipment only responds sensitively to magnetic substances, and has a good elimination performance for products with moisture and frozen products.The device can detect metals such as iron and non-iron, and can be widely used for metal detection in demanding objects such as food, medicine and toys.

Use:

Metal Detector For Food industry is widely used in the detection of meat, frozen meat, sea food, mushrooms, drinks ,fruits , Sugar, Salt and vegetables. Rejection System Food Metal Detector can detect ferrous and non-ferrous and other metal objects , the sensitivity can be adjusted separately , with memory function can be stored 10 kinds of test material·Detector with audible and visual alarm , and automatically exclude , stop , rewind functions , user-friendly menu , easy to operate touch screen.



Feature:

1. Double circuit electromagnetic wave detection, new analog circuit and digital circuit combination, improve the sensitivity and reliability of detection.

2. The new type of touch screen input and composition of large scale integrated circuit improve the intelligence of detection (LIQUID crystal type).

3. User-friendly interface design, multi-language operation, the whole process is simple and intuitive, human-machine interface at a glance (LIQUID crystal).

4. Dynamic zero point voltage tracking, automatic learning detection function, reduce personnel operation.

5. Wide adjustable range of sensitivity, with reverse detection function (no alarm for metal products, no alarm for metal products).

6. When metal is detected, sound, light and alarm will be given at the same time, and the machine will stop or kick out the unqualified products (optional functions).

Parameter:

Detected Height(mm) 80 100 150 200 250 300 350
Belt Width(mm) 250 250 400 400 400 400 400
Belt length 1500
Detector sensitivity(mm) Fe 0.8 Fe 1.0 Fe 1.2 Fe 1.5 Fe 2.0 Fe 2.5 Fe 3.0
SUS 1.0 SUS2.0 SUS2.5 SUS2.5 SUS3.0 SUS3.5 SUS4.0
N-Fe 1.0 N-Fe1.5 N-Fe2.0 N-Fe2.0 N-Fe2.5 N-Fe3.0 N-Fe3.5
Speed of belt

25M/min (Fixed speed) ;

If you need adjust 5-40 M/min , please inform us before order

Load ability 20KG
Count 100
Warning method ound and light alarm ; The belt can be stopped, continue run or belt return ( the option you can selected in PLC controller)
Reject Ways when has auto-reject system ,belt continue and rejecting the goods
Application Non-package ,plastic package ,paper bag or box (non-metallic) product
Work Environment Temperature -10℃-40℃ ,relative humility 30-90%



Product Paramenters

Model
BOTO-3015

 BOTO-4015

BOTO-4020

  BOTO-

  4025

BOTO-5020
BOTO-5030
BOTO-6040
Detector Dimension (Width*HeightMM)
300*150
400*150
400*200
400*250
500*200
500*300
600*400
Belt width(MM)
280
370
370
370
470
470
570
Transfer speed
25m / min
Transfer ability
5KG
5KG
7KG
7KG
7KG
7KG
25KG
Sensitivity
FE
1.0mm
1.0mm
1.2mm
1.5mm
1.5mm
2.5mm
3.0mm
NON-FE
1.5mm
1.5mm
2.3mm
2.5mm
2.0mm
3.0mm
4.0mm
SUS304
2.0mm
2.3mm
2.5mm
3.0mm
2.5mm
3.5mm
4.5mm
Operation interface
10 inches color LCD screen
Operating mode
Plane key input (touch optional)
Item memory
100 Products
Stable way
Automatic phase adjustment
Alarm mode
Buzzer,Alarm lamp,Alarm stop Run
Rejector(optional)
Flip Bar Type,Air Blast Type,Pusher on Roller Type,Pusher on Belt Type,Drop Flap Type, Chute Type,Conveyor Retraction Type(other types need to customization)
External interface
USB,RS232/485/422,to store data,Voltage signal or Switch signal,TCP/IP(optional)
Corollary equipment
Ink-jet printer,Check Weigher,Online printer,Labeling machine, etc
Power Source
380/220/110V 50/60Hz
Power Output
About 200W
Measurement
SUS304
Degree of protection
IP54/IP65(IP66 need to be custom)
Environment
0℃-50℃
Remark
1.Above the detection sensitivity is empty machine belt surface accuracy and practical sensitivity by products, environment or metal into position influence.
2.Above machine specifications for the standard specifications, size and other special
requirements, all can be customized.





110V Chocolate Sus304 Industrial Conveyor Metal Detector Food Processing 0





110V Chocolate Sus304 Industrial Conveyor Metal Detector Food Processing 1









The sample service

1.We can send you the video of the running machine.

2.You are welcome to come to visit our factory,and see the machine running.

Castomized service

1.We can design the machines according your requirements(materil,power,filling type,the kinds of the bottles,and so on),at the same time we will give you our professional suggestion,as you know,we have been in this industry for many years.

After-sales service

1.We will delivery the machine and provide the bill of load on time to make sure you can get the machine quickly

2.. We often ask feedback and offer help to our customer whose machine have been used in their factory for some time.

3..We provide one year warranty

4.Well-trained & experienced staff are to answer all your inquiries in English and Chinese

5 .12 Months guarantee and life-long technical support.

6.Your business relationship with us will be confidential to any third party.

7. Good after-sale service offered, please get back to us if you got any questions.
Product packaging
110V Chocolate Sus304 Industrial Conveyor Metal Detector Food Processing 2
FAQ
1.Are you manufacturer or trader? Where are your factory located?
We are manufacturer and we are located in Shanghai,China.

2.What kind of Transportation could you provide?And are you able to update the production process Information in time after placing our order?
Sea shipping, air Shipping, and international express. And after confirming your order ,we would keep you updated of production details of emails and photos.

3.How long is your warranty?
12 months free warranty, life-long maintenance.

4.Are you provide product metal parts and provide us technical guidance?
Wearing parts,for example, motor belt,Disassembly tool(free) are what we could provide.And we can give you technical guidance.

5.What are your company requests of payment terms?
TT,L/C,International Credit Card.

6. What is the validity time of the quotation?
15 days since quotation date

7. What is the delivery time?
Within 15 days after receipt of your deposit.

8. Are you a manufacturer?
Yes, we are a manufacturer, and we can provide the competitive price and good quality.
