-70℃ ~ +120℃ Walk In Test Chamber , Double Door Temperature Humidity Chamber

China -70℃ ~ +120℃ Walk In Test Chamber , Double Door Temperature Humidity Chamber supplier
-70℃ ~ +120℃ Walk In Test Chamber , Double Door Temperature Humidity Chamber supplier -70℃ ~ +120℃ Walk In Test Chamber , Double Door Temperature Humidity Chamber supplier -70℃ ~ +120℃ Walk In Test Chamber , Double Door Temperature Humidity Chamber supplier -70℃ ~ +120℃ Walk In Test Chamber , Double Door Temperature Humidity Chamber supplier

Large Image :  -70℃ ~ +120℃ Walk In Test Chamber , Double Door Temperature Humidity Chamber

Product Details:

Place of Origin: CHINA
Brand Name: HST
Certification: CE ISO FCC
Model Number: HST-5166

Payment & Shipping Terms:

Minimum Order Quantity: 1 SET
Price: Negotiable
Packaging Details: Standard Export Wooden Package
Delivery Time: 7-20 days
Payment Terms: T/T, Western Union
Supply Ability: 500 sets/month
Contact Now
Detailed Product Description
Humidity Constancy: ±2.0%R.H Application: Double Door
Interior Material: Stainless Steel Plate(SUS 304) Heat Up Time: +20 ºC~+80 ºC,Within 60 Min
Ambient Temp: -70℃~+120℃ Humidity Range: 10%,20%,30%~95%
Controller: LCD Toch Panel Temp. Uniformity: ±1.0 ºC

-70℃~+120℃ Double Door Temperature Humidity Test Chamber Walk-In Environmental Test Chamber

Application
The environmental room can heat all types of batteries.
These special tests for sensitive products, human safety and product safety can be broadly considered and solutions based on the risks involved.

In the case of possible leakage of the device under test:
exhaust pipe
Manufacture of photovoltaic (PV) module testing standard environmental room.
In accordance with the standards achieved, important special considerations were taken into account in.


Main Parameters

Model KMHW
Temp Maximum: 80 ºC,120 ºC and more higher
Minimum: -60 ºC, -50 ºC, -40 ºC, -30 ºC, -20 ºC, -10 ºC, 0 ºC
Humidity 10%, 20%, 30% ~ 95%
Heat up time +30 ºC~+90 ºC, Within 50 min
Pull down time +30 ºC ~ -55 ºC, -40 ºC,Within 60 min
Interior material Stainless Steel Plate
Exterior material Baked Painting Steel Or Stainless steel
Insulation material Rigid polyurethane foam



Core system

Refrigeration System
Compressor German GEA Bock semi-hermetic compressor
Refrigerant Non-fluorine environmental friendly refrigerant: R404a, in line with environmental regulations, safe, non-toxic
Condenser Automatic heat dissipation High efficiency finned radiator (air cooled).
Evaporator Fin-type multi-stage automatic load capacity adjustment
Other accessories High-precision expansion valve, desiccant, and other components are imported internationally famous brands.
Expansion system Multi-stage adjustable energy consumption output control of the refrigeration system
Condensate dispose Condensate water produced by refrigeration system will be collected by the water tray, and drained out together with the condensate generated by test chamber through pipe.
Refrigeration Technology

※ Nitrogen welding, two-stage rotary vane vacuum pump, ensure that the internal cooling system clean and reliable.
※ water tray located at the bottom of the compressor to ensure condensate water drain through pipe freely at the rear of the chamber.

Control System
Sensor High precision DIN A class, Dry ballφ4.8mm SUS #304 PT 100Ω.
Controller

HASTON Programmable HST-5166 LCD Touch Screen Controller with PID control parameters setting



Display Function

Temperature and humidity settings (SV) Practical (PV) value can be displayed directly;
Execution of the program can display numbers, paragraphs, remaining time and cycles, running time display,
Program editing and graphic curve display,
Fixed or program operation status display,
Resolution: 800*480, 10-inch TFT display screen.
Language: Russian / Chinese

Display
Resolution

Temperature: + 0.01℃; Humidity: + 0.1%; time: 1min.
Setting Range

Temperature conditions: -100~+200 ℃;
Temperature can be adjusted based on the working temp. range of the equipment (the upper limit: +5℃, the lower limit : -5℃)
Humidity conditions: 0~100 %RH.

Operation Mode Programmable running, constant running
Program capacity

Set the running time to reach 9999 h 59 m (Setting of 0 : constant operation without time limit);
Available program capacity: Up to 1000 groups;
Available memory capacity: Each group of 1000 steps;
Repeated executive commands: Each command /program can be up to 999 cycles.

Setting Mode Human-machine interface, Touch Mode Input and control.
Communication Interface

Data collection and curve display when connected to a computer
Can be used as monitoring and remote control system
Multiple machines synchronization control available
RS-232, RS-485 and Ethernet.
(for remote control from PC and storage data from controller to PC HDD)
+ USB type A (for storage data from controller to USB-flashdrive)

U Disk Memory Card 1G-8G available for downloading historical curve, data, pluggable
Data Collection

RAM with battery protection, setting(SV), Practical(PV) and sampling time can be saved;
The curve recording period can be set 10~60 sec. Maximum historical data memory storage is 90 days, historical data (When sampling).

Power Off Memory Function Power recovery mode can be set as hot start, cold start and stop
Pre-set Function Boot time can be set freely and machine runs automatically when turning on power
Software Environment Windows 2000 or Windows XP
Network Connection Can be connected to Ethernet via professional software, remote control & assistance function and data collection can be achieved through network, , multiple machine can be controlled simultaneously
Control panel

a. Emergency stop switch
b. switch
c. Over-temperature protector *1
d. RS-485 interface *1

Protection System

a. Residual current circuit breaker (RCCB)
b. Heater overtemperature protection switch;
c. Circulating fan over current overload protection;
d. Compressor overpressure protection;
e. Compressor overheating protection;
f. Compressor over-current protection;
g. Overvoltage lack phase, anti-phase protection switch
h. Breaker;
i. humidifier overtemperature protection switch;
j. heater overcurrent protection switch
k. humidifier overcurrent protection switch
l. Humidifier low water level protection
m. Water tank low water level warning
n. Controller noise isolation protection
o. Zero-crossing thyristor power controller


Our service

1. Considerate Service Different countries plugs, manually change the-voltage from 110V to 220V, insurance indicator.



2.Excellent After sale Service:
12 months warranty. Besides, we can help you to repair your problem controller freely, even it's not from our factory. What you need to do is to send us the controller.



3.Commitment:
We will sign a letter of commitment while we sign the contract, which will improve your confidence to us.



4.Good Packaging:

Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
