Temperature Range:: | 0℃~70℃ | Ozone Concentration:: | 50~500pphm |
---|---|---|---|
Test Set-Up:: | Dynamic, Static (Optional) | Gas Flow Rate:: | 12~16mm/S |
Ozone Generator:: | Silent Discharge Tube Type | Power:: | Electronic |
Moistrure Range:: | 30~65%R.H | Keyword:: | Ozone Aging Test Chamber |
Temperature Fluctuation Degree:: | ±0.5℃ | Sample Frame Speed:: | 360 Degree Rotating Sample Holder |
Time Controller:: | High Precision Hour, Minute And Second Time Controller | ||
High Light: | Ozone Corrosion Aging Test Machine,16mm/S Aging Test Machine,65%RH Aging Test Machine |
Temperature Range | 0℃~70℃ |
Moistrure Range | 30~65%R.H |
Ozone Concentration | 50~500pphm |
Temperature Fluctuation Degree | ±0.5℃ |
Test Set-Up | Dynamic, Static (Optional) |
Sample Frame Speed | 360 Degree Rotating Sample Holder (Speed 1 Rpm) |
Gas Flow Rate | 12~16mm/S |
Temperature Controller | Imported LED Digital Display P.I.D + S.S.R. Microcomputer Integrated Controller |
Time Controller | High Precision Hour, Minute And Second Time Controller |
Ozone Concentration Analysis | Import Concentration Analysis Regulator 4~20mA Output, RS232 Communication Port |
Ozone Generator | Silent Discharge Tube Type/UV Absorption Type (Optional) |
Security Protection |
Leakage, Short Circuit, Over Temperature, Motor Overheating, Over Current Protection
|
Ozone is present in very small amounts in the atmosphere, but is a major factor in rubber cracking.
Ozone aging chamber is to simulate and enhance the ozone environment in the atmosphere. Studied the effect of ozone on rubber, fast identification and evaluation of rubber ozone aging resistance and antiozonant shielding efficiency of the method, and then take effective measures, the anti aging in order to improve the service life of rubber products.
This series of products are suitable for nonmetallic materials, organic materials (coating, rubber, plastic, paint, pigment, etc.) under the condition of ozone aging test.
All sizes of products can be customized.
