| Place of Origin: | China |
|---|---|
| Brand Name: | BOTO |
| Certification: | MIL STD GB JIS JEDEC IEC ISO |
| Model Number: | B-ZW |
| Minimum Order Quantity: | 1PCS |
| Price: | Discussible |
| Packaging Details: | wooden case |
| Delivery Time: | 15days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 1000PC/Month |
| Model: | B-ZW | Ultraviolet Wavelength: | 290nm-400nm UV-A、UV-B、UV-C |
|---|---|---|---|
| Internal: | 45x117x50 | External Dim: | 58x128x135 |
| Humidity Range: | ≥95%R.H | Distance Between Tubes: | 35mm |
| Distance Between Sample And Tube: | 50mm | Material: | 304Stainless Steel Plate |
| Lamp Wattage: | 40W | Safety Protection: | Leakage, Short Circuit, Over Temperature, Water Shortage, Over Current Protection/controller Power Failure Memory |
Environmental Test Chambers VG95218-2 UV Aging Test Chamber B-ZW Climatic Chamber 290nm-400nm UV-A Mathine
UV weathering test chamber is to simulate the sun lighting, and it’ s specialized in the simulation of products in outdoors for a long time. The ultraviolet radiation in the sun is destructive on its exposure, only a few days or weeks, the equipment can
reproduce the destruction outdoors for months or years. And then to see whether the product has fading, discoloration, brightness decline, powder, cracking, blurred,brittle, decreased strength and oxidation phenomena, while it can reproduce the
destruction of rain and dew.
There are several different types of fluorescent UV lamps that have unique spectral characteristics. Fluorescent black lights, referred to as UV-A lamps, are available with peak emissions of 340 nm – 370 nm (e.g., UVA-340 and UVA-351). In the UVA-340 lamp, the short wavelength irradiance simulates that of direct solar radiation below 325 nm. Fluorescent UV-B lamps (UVB-313), with a peak around 313 nm, have nearly all of their energy concentrated between 280 nm and 360 nm. A large percentage is at wavelengths shorter than what is present in natural sunlight. There is very little radiation with wavelengths longer than 360 nm. Reversals in the stability ranking of materials have often been reported between laboratory accelerated and outdoor tests when the accelerated test uses UV-B lamps. This occurs because of the large amount of short wavelength UV and the lack of long wavelength UV and visible radiation; the mechanisms of degradation may be significantly different from those of the “natural” tests.
The UV aging test chamber simulates the effect of sunlight with fluorescent ultraviolet(UV) lamps and carry out these circles automatically.While it simulates rain and dew with condensing humidity or waterspray.In a few days or weeks,the UV can reproduce the damage that occurs over months or years outdoors.The damages include fading,color change,chalking,cracking,crazing,embrittlement,strength loss,etc.The test data can help you to select the new materials or improve the performance of materials. Chamber cover introduces the two-way flip type for easy opening and closing.The spec-imen and the shelf constitute the trapezidal inner wall of the chamber.
Innova UV Aging test chamber designing Standard: IEC61215, ASTM D4329, D499, D4587, D5208, G154, G53; ISO 4892-3, ISO 11507; EN 534; prEN 1062-4, BS 2782; JIS D0205; SAE J2020, ect.
It has the following performance characteristics:
The heating mode is the inner tank heating, fast heating and uniform temperature distribution
The drainage system uses reflux type and U-type sedimentation device to drain water
The distance between the sample surface and the UV lamp plane is 50 mm and parallel
The actual studio consists of test samples and supports to form the inner wall of the box, trapezoidal
Automatic water refill of tank water level
The lid is bidirectional clamshell type, easy to open and close
High quality fixed PU movable wheel is used at the bottom of the test chamber
Model |
B-ZW | ||||
Internal Dim(DxWxH) |
50x75 | ||||
| External Dim(DxWxH) | 58x128x135 | ||||
| power(kw) | 4KW/3.2kW | ||||
| performance index | Temperature range | RT+10℃-70℃ | |||
| Humidity range | ≥95%R.H | ||||
| Distance between tubes | 35mm | ||||
| Distance between sample and tube | 50mm | ||||
| ultraviolet wavelength | 290nm-400nm UV-A,UV-B,UV-C | ||||
| Lamp wattage | 40W | ||||
| safety protection | Leakage, short circuit, over temperature, water shortage, over current protection/controller power failure memory | ||||
Packing/Shipping:
During the whole business process, we offer Consultative Selling service.
1)Customer inquiry process:
Discussing testing requirements and technic details, suggested suitable products to customer to confirm. Then quote most suitable price according to customer requirements.
2)Specifications customize process:
Drawing related drawings to confirm with customer for customized requirements. Offer reference photoes to show the proucts appearance. Then, confirm the final solution and confirm final price with customer.
3)Production and delivery process:
We will produce the machines according to confirmed PO requirements. Offering photoes to show production process.
After finish production, offer photoes to customer to confirm again with the machine. Then do own factory calibration or third party calibration(as customer requirements). Check and test all the details and then arrange packing.
Deliver the products in confirmed shipping time and inform customer.
4)Installation and after sale service:
Defines installing those products in the field and providing after-sales support.
