Small High And Low Temperature Test Chamber Lab Humidity Chamber BT-107 Dry Chamber

Basic Information
Place of Origin: China
Brand Name: BOTO
Certification: CE ISO
Model Number: BT-107(A~D)
Minimum Order Quantity: 1 SET
Price: 1500USD
Packaging Details: Export carton
Delivery Time: 25 work days
Payment Terms: L/C, T/T
Supply Ability: 1000set/month
Usage: Lab Test Heat-up Time: About 3-5°C/min
Pull-down Time: About 0.7-1°C/min Tem Fluctudtiont: ±0.5°C
Temperature Range:: -70℃~+150℃ (or Customized) Power Source: AC220V 50/60Hz
PowerElectronic: 1-2KW Material: SUS 304 Stainless Steel
Temp Deviation: ±0.1℃ Controller: OTS Designed Controller With LCD Touch Screen

Small High And Low Temperature Test Chamber Lab Humidity Chamber BT-107 Dry Chamber

Product Description:

A high and low temperature test chamber is a specialized piece of equipment used in research and development laboratories, quality control departments, and manufacturing facilities to test the thermal resistance of materials and components. This type of chamber can simulate extreme temperature conditions, both high and low, to determine how a product or material will perform under different temperature ranges.

The high and low temperature test chamber consists of an insulated chamber with a heating and cooling system, which allows the temperature to be controlled and regulated to specific levels. The temperature range of the chamber can vary depending on the application, with some chambers capable of reaching temperatures as low as -70°C and as high as 150°C.

During testing, the material or product is placed inside the chamber and exposed to the extreme temperature conditions for a predetermined amount of time. The performance of the product is then evaluated based on its ability to withstand the temperature changes and maintain its structural integrity.

High and low temperature test chambers are commonly used in the aerospace, automotive, electronics, and medical industries to test the durability and reliability of products and components. They are also used in research and development to study the effects of temperature on materials and to develop new materials that can withstand extreme conditions.



Type Inner size Shape size
H/HWHS-50L 350×350×400mm 885×850×1320mm
H/HWHS-100L 400×500×500mm 935×1000×1420mm
H/HWHS-150L 500×500×600mm 1035×1000×1520mm
H/HWHS-225L 500×600×750mm 1060×1130×1700mm
H/HWHS-408L 600×800×850mm 1135×1300×1800mm
H/HWHS-500L 700×800×900mm 1235×1300×1850mm
H/HWHS-800L 800×1000×1000mm 1435×1400×1950mm
H/HWHS-1000L 1000×1000×1000mm 1535×1500×1950mm

3. Specifications

Temperature range:-50ºC~150ºC
Temperature fluctuation:≤±0.5ºC (no load)
Temperature uniformity:≤±2ºC (no load)
humidity range:30~98%R.H(The temperature is 25-80ºC)
Humidity evenness:+2~-3%(>75%RH),±5%(≤75%RH)
Analytic accuracy: temperature:0.1ºC humidity:0.1%RH
heating rate:1~3ºC/min (When no load, the whole journey average)
rate of temperature fall:0.7~1.5ºC/min (When no load, the whole journey average)
total power: about12KW
power supply: 380v 50hz



Small High And Low Temperature Test Chamber Lab Humidity Chamber BT-107 Dry Chamber 0

Small High And Low Temperature Test Chamber Lab Humidity Chamber BT-107 Dry Chamber 1

Small High And Low Temperature Test Chamber Lab Humidity Chamber BT-107 Dry Chamber 2



Application:



Temperature humidity drug stability test chamber price can be used when constant climate conditions (temperature and/or



humidity) are needed for product testing. It also can be used for a variety of materials of high - low temperature alternating test.



The test temperature, humidity, time can be programmed. Provides conditions of temperature from -70 to +150 degree and of



humidity from 20% to 98%, low humidity 10%~98%RH is available for us.



Small High And Low Temperature Test Chamber Lab Humidity Chamber BT-107 Dry Chamber 3



Company Profile



BOTO GROUP Ltd. is a private enterprise integrating R&D, production, OEM and sales of scientific and technological equipment manufacturing. Proficient in the production, development and upgrading of various non-standard instruments and automatic instruments. The factory covers an area of 26,666 square meters, headquartered in Shanghai, has several offices in China, the factory annual output of about 2000 sets of equipment. Since the establishment of the company, the company is committed to providing customers with quality products and services, and has been praised by customers.



Small High And Low Temperature Test Chamber Lab Humidity Chamber BT-107 Dry Chamber 4

Small High And Low Temperature Test Chamber Lab Humidity Chamber BT-107 Dry Chamber 5

Main equipment

Small High And Low Temperature Test Chamber Lab Humidity Chamber BT-107 Dry Chamber 6

In the domestic market, we have many end customers, third-party testing institutions, research institutes, leading enterprises in different industries, and some agents. For the overseas market, we hope to find more general agents, distributors and importers to cooperate together.



Main market

Small High And Low Temperature Test Chamber Lab Humidity Chamber BT-107 Dry Chamber 7



The factory has the ability to calibrate, and the customer can also designate a third party organization to calibrate and issue a calibration report.



Production Process

Small High And Low Temperature Test Chamber Lab Humidity Chamber BT-107 Dry Chamber 8

Small High And Low Temperature Test Chamber Lab Humidity Chamber BT-107 Dry Chamber 9

Small High And Low Temperature Test Chamber Lab Humidity Chamber BT-107 Dry Chamber 10

Small High And Low Temperature Test Chamber Lab Humidity Chamber BT-107 Dry Chamber 11



Production Details

Small High And Low Temperature Test Chamber Lab Humidity Chamber BT-107 Dry Chamber 12

Small High And Low Temperature Test Chamber Lab Humidity Chamber BT-107 Dry Chamber 13

Small High And Low Temperature Test Chamber Lab Humidity Chamber BT-107 Dry Chamber 14

Small High And Low Temperature Test Chamber Lab Humidity Chamber BT-107 Dry Chamber 15



Factory Inspection
We control quality from the materials, electronic parts, controller,comppressor, solenoid valve, and many parts of the products.



Certification

Small High And Low Temperature Test Chamber Lab Humidity Chamber BT-107 Dry Chamber 16

Cooperative partners

Small High And Low Temperature Test Chamber Lab Humidity Chamber BT-107 Dry Chamber 17



BOTO ADVANTAGE

Small High And Low Temperature Test Chamber Lab Humidity Chamber BT-107 Dry Chamber 18

Our Services

During the whole business process, we offer Consultative Selling service.

1) Customer inquiry process:

Discussing testing requirements and technical details, suggested suitable products to customer to confirm. Then quote most suitable price according to customer requirements.

2) Specifications customize process:

Drawing related drawings to confirm with customer for customized requirements. Offer reference photos to show the products appearance. Then, confirm the final solution and confirm final price with customer.

3) Production and delivery process:

We will produce the machines according to confirmed PO requirements. Offering photos to show production process.

After finish production, offer photos to customer to confirm again with the machine. Then do own factory calibration or third party calibration(as customer requirements). Check and test all the details and then arrange packing.

Deliver the products in confirmed shipping time and inform customer.

4) Installation and after sale service:

Defines installing those products in the field and providing after-sales support.
