Model: | B-XD-408 | Internal: | 60x85x80 |
---|---|---|---|
External Dim: | 122x168x112cm | Tenperature Range: | RT+10℃-70℃ |
Relative Humidity Range: | 50%-90%RH | Power: | 2KW/6KW |
It has the following performance characteristics:
1. Adopt full-spectrum xenon lamp luminescent tube;
2, a variety of filter system for choice;
3, rain spraying function;
4. Relative humidity control.
5, test chamber air temperature control system;
Model |
B-XD-120 | B-XD-225 | B-XD-408 | B-XD-800 | |
Internal Dim(W*H*D) |
45x60x45 | 50x75x60 | 60x85x80 | 100x100x80 | |
External Dim(W*H*D) | 107x145x68 | 120x164x92 | 122x169x112 | 162x184x112 | |
Temperature range | RT+10℃~70℃ | ||||
Humidity range | 50%~90%RH | ||||
Radiation intensity of xenon lamp | 550W/m² | ||||
Spectral wavelength region | 290nm-800nm | ||||
rainfall time | 0-9999/min | ||||
Total power xenon lamp | 2KW/6KW | ||||
type of cooling | forced air cooling/water-cooling | ||||
Interior | SUS#304Stainless steel plate | ||||
External material | Coating or SUS#304Stainless steel plate | ||||
Power Source |
AV:220V/380V 50/60Hz |
