| Place of Origin: | China |
|---|---|
| Brand Name: | UV aging test chamber |
| Certification: | ISO CE |
| Model Number: | BT-08 |
| Minimum Order Quantity: | 1 |
| Price: | Negotiable |
| Packaging Details: | Plywood wooden case |
| Delivery Time: | 10-15 |
| Payment Terms: | T/T |
| Supply Ability: | 1000/month |
| Temperature Uniformity: | ±1℃ | Product Name: | UV Aging Test Chamber |
|---|---|---|---|
| Temperature Fluctuation: | ±0.5℃ | Humidity Range: | ＞90%RH |
| Standard Test Piece: | 75×150mm/21 Pieces | UV Intensity: | 0.30-1.1W/㎡ |
| Material: | 304 Stainless Steel | Chamber Size: | 550× 1300× 1480mm (D×W×H) |
| High Light: | SS UV Radiation Testing Equipment,SS304 UV Radiation Testing Equipment,304 Stainless Steel UV Test Chamber |
||
The UV Test Chamber is a state-of-the-art UV radiation durability testing equipment designed for product resistance to light aging performance testing. It is an ideal material aging performance testing instrument which provides accurate results for a wide range of applications. This device is capable of testing the light aging performance of a variety of materials including plastic, rubber, fabrics, paints, coatings and many more. It features a user-friendly design with a standard test piece of 75×150mm/21 pieces and a temperature range of RT+10℃-70℃. Furthermore, it has a humidity range of more than 90%RH and a UV intensity of 0.30-1.1W/㎡. This product is reliable and efficient, providing users with accurate results to ensure the durability of their products.
| Model | BT-08 UV aging testing machine |
| Temperature range: | RT+10℃～70℃ |
| Temperature fluctuation: | ±0.5℃ |
| Temperature uniformity: | ±1℃ |
| Humidity range: | ≥90%RH |
| Center distance in lamp tube: | 70mm |
| The distance between the test product and the center of the lamp tube: | 50±3mm |
| Ultraviolet tube: | UVA-340 wavelength range 290-400nm (its peak value is 340nm) UVB-313 wavelength range 280-315nm (Its peak is 313nm) |
| Standard test piece: | 75×150mm/21 pieces |
| Irradiation intensity: | 0.30-1.1W/㎡/adjustable 313nm, 340nm band (setting the irradiation intensity value through the touch screen) |
| Irradiation control: | Intelligent control of irradiance, real-time feedback of the irradiance value detected by the irradiance sensor, compared with the set value of the irradiation on the touch, and then the lamp ballast is controlled by the output voltage of the PLC , And finally realize the control of the brightness of the lamp tube, so as to adjust the irradiance PID setting and automatically compensate the set value. |
| Compliant with standards: | GB/T 14522-93 ASTM G 154, ISO 4892-1 ISO 11507 ASTMD 4329 |
UV Test Chamber is a reliable and efficient product for UV radiation aging test, which is widely used in material aging performance testing and UV aging test. This product, with the brand name of UV aging test chamber, model number of BT-08 and certificated with ISO CE, is manufactured by our company in China. The minimum order quantity is 1 with a negotiable price, and the delivery time is 10-15 days. The payment term is T/T and the supply ability is 1000/month. Besides, the UV intensity is 0.30-1.1W/㎡, the UV wavelength is 290-400nm, the chamber size is 550× 1300× 1480mm (D×W×H) and the humidity range is ＞90%RH. The product is well packed in plywood wooden case for transportation. UV Test Chamber provided by us is excellent in terms of quality, performance, accuracy and durability.
Brand Name: UV aging test chamber
Model Number: BT-08
Place of Origin: China
Certification: ISO CE
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Plywood wooden case
Delivery Time: 10-15
Payment Terms: T/T
Supply Ability: 1000/month
Material: 304 Stainless Steel
Standard test piece: 75×150mm/21 Pieces
Chamber Size: 550× 1300× 1480mm (D×W×H)
Temperature Uniformity: ±1℃
Product Name: UV Aging Test Chamber
Keywords: UV radiation durability testing equipment, Product resistance to light aging performance testing device, UV radiation durability testing equipment
We provide technical support and service for UV Test Chamber. Our support team is available 24/7 and can provide assistance with installation, maintenance, and troubleshooting. We also offer a warranty on all our products to ensure that you get the best performance out of your UV Test Chamber.
In addition, we offer a variety of online resources to help you get the most out of your UV Test Chamber. These include product manuals, instructional videos, FAQs, and more. We also provide a variety of customer service solutions to ensure that you get the help you need when you need it.
Packaging and Shipping for UV Test Chamber:
