| Place of Origin: | China |
|---|---|
| Brand Name: | High and low temperature chamber |
| Certification: | CE ISO |
| Model Number: | B-TH-120 |
| Minimum Order Quantity: | 1 set |
| Price: | Negotiable |
| Packaging Details: | wooden |
| Delivery Time: | 15 days |
| Payment Terms: | T/T |
| Supply Ability: | 3000sets/mouth |
| Humidity Uniformity: | ±3% RH | External Dim: | 75x189x110 |
|---|---|---|---|
| Chamber Construction: | Stainless Steel | Chamber Dimensions: | Customizable |
| Control System: | Programmable | Humidity Range: | 10% To 98% RH |
| Product Name: | Environmental Test Chambers | Temperature Range: | -70C To +150°C |
| High Light: | Precise Humidity Control Environmental Test Chambers,Stainless Steel Environmental Test Chambers,Programmable Environmental Test Chambers |
||
Our chambers provide exceptional temperature uniformity, with a range of ±1°C, making them ideal for thermal cycling chambers and stability testing chambers. Additionally, our temperature and humidity control chambers offer precise control over both variables, ensuring highly accurate test results.
Our chambers come equipped with a range of accessories, including data loggers, chart recorders, and humidity generators. These tools allow for even more precise control over testing conditions and provide detailed data for analysis.
When it comes to safety, our Environmental Test Chambers are designed with multiple features to protect both the chamber and its contents. Over-temperature protection, over-pressure protection, and over-humidity protection all work together to ensure a safe testing environment.
Our Environmental Test Chambers are also certified by UL, CE, RoHS, and other organizations, ensuring that they meet the highest safety and quality standards.
The Environmental Conditioning Chambers can be used for testing products like electronics, automotive parts, rubber, plastic, and other materials that need to operate in extremely high or low temperatures. This equipment can be used in a variety of scenarios such as research and development, quality control, and product testing. It is a highly reliable and cost-effective testing solution for a wide range of industries.
The Climate Controlled Test Chambers is designed with insulation made of fiberglass to ensure high thermal efficiency and accuracy. The temperature accuracy is ±0.5°C, and the power source is AC:220V/380V 50Hz/60Hz. The Humidity Range is 10% to 98% RH, and the chamber volume is 1.0 to 1000.0 Cu. Ft. This equipment is suitable for testing products that are sensitive to humidity and temperature changes.
The Climate Controlled Test Chambers can be used in a variety of applications such as testing the thermal stability of electronic components, determining the durability of automotive parts, and testing the reliability of materials used in aerospace and defense industries. This equipment is highly reliable and can provide accurate and consistent results, making it an essential tool for research and development, quality control, and product testing.
Specifications
| Model | BT-280 | BT-2150 | BT-2225 | BT-2408 | BT-2800 | |
|
Inner Size W×H×D(cm) |
40×50×40 | 50×60×50 | 50×75×60 | 60×85×80 | 100×100×80 | |
|
Outside Size W×H×D(cm) |
93×155×95 | 100×148×106 | 117×166×91 | 140×176×101 | 170×186×111 | |
| Volume (V) | 80 L | 150L | 225L | 408L | 800L | |
| Temp and Hum Range |
A:-20°C~150°C B: -40°C~150°C C: -60°C~150°C D: -70°C~150°C RH20%-98% |
|||||
| Function | Fluctuation | ±0.5°C ±2.5%RH | ||||
| Deviation | ±0.5°C-±2°C ±3%RH(>75%RH); ±5%RH(≤75%RH) | |||||
|
Controller Analytical Accuracy |
±0.3°C ±2.5%RH | |||||
| Wind Cycling Way | Centrifugal fan-broadband type forced air circulation | |||||
| Refrigeration Way | Single stage compression refrigeration | |||||
| Refrigerator | French Tecumseh | |||||
| Refrigerants | R4O4A USA DuPont environmental protection refrigerant(R23+R404) | |||||
| Condensing Way | Air-cooled or water-cooled | |||||
| Water Supplying Way | Automatic cycling water supply | |||||
| Safety device |
Non- fuse-switch(compressor overload, refrigerant high low voltage, over-humidity and temperature protection, Protection switch,fuse stoppage warning system |
|||||
Our Environmental Test Chambers come with a comprehensive technical support and service package to ensure optimal performance and longevity. Our team of experienced technicians are available to provide installation, maintenance, and repair services as needed. In addition, we offer calibration and validation services to ensure accurate and reliable test results. Our technical support team is also available to provide assistance with any questions or issues that may arise during testing. We are committed to providing our customers with exceptional support and service to ensure their complete satisfaction with our Environmental Test Chambers.
