|Speed:||100-300RPN Cir/min||Amplitude(P-P):||1 Inches(25.4mm)+15%Meet ISTA/EN71 Transport Standards|
|Working Time Setting Range:||0~99.99hours||Speed Display Accuracy:||0.1RPN Cir/min|
|Digital Display Speed::||Accuracy Is Not Greater Than ±3cir/min||Power Supply:||220V 50Hz Single-phase|
Professional Altitude Test Chamber / Vibration Table Testing Equipment For Automobile
is based on the United States and European transport standards, and with reference to the United States of similar equipment to improve manufacturing. The use of eccentric bearings in rotating elliptical trajectories generated to simulate a car or ship the goods during transport the vibration of the collision. Test platform will be fixed on the eccentric bearing, when the eccentric bearing rotation, the test platform for the entire plane would produce an oval-shaped upper and lower front and rear movement, adjust the eccentric shaft with the rotation speed is equivalent to adjust the speed of motor vehicles or vessels.
1. Digital instrument display vibration frequency;
2. synchronous belt transmission mute, very low noise;
3. test items using clamping rail type, easy to operate, safe;
4. machine using heavy-duty channel steel base with anti-vibration pad, easy installation, smooth operation, without Install ground pin screw;
5. DC motor speed control, running smoothly, load capability;
6. rotary vibration (commonly known as Valley-type).
This transportation simulator vibration machine meets the following standards: GB / T 4857.7-92 "transport package fixed-frequency sinusoidal vibration test method"
The country road transportation simulator vibration simulator applies to toys, electronics, furniture, gifts, ceramics, packaging and other products packaged to simulate the transport tests, in line with the United States and European transport standards.
|Speed display accuracy||0.1RPN cir/min|
|Vibration mode||Reciprocating type|
|Amplitude(P-P)||1 inches(25.4mm)+15%Meet ISTA/EN71 transport standards|
|Maximum payload||100 pounds|
|Digital display speed||Accuracy is not greater than ±3cir/min|
|Working time setting range||0~99.99hours|
|Power supply||220V 50Hz Single-phase|
