150L High Temperature Test Chamber Inner Water Supply Mode 7 Inch TFT Display Screen

China 150L High Temperature Test Chamber Inner Water Supply Mode 7 Inch TFT Display Screen supplier
150L High Temperature Test Chamber Inner Water Supply Mode 7 Inch TFT Display Screen supplier 150L High Temperature Test Chamber Inner Water Supply Mode 7 Inch TFT Display Screen supplier 150L High Temperature Test Chamber Inner Water Supply Mode 7 Inch TFT Display Screen supplier 150L High Temperature Test Chamber Inner Water Supply Mode 7 Inch TFT Display Screen supplier

Large Image :  150L High Temperature Test Chamber Inner Water Supply Mode 7 Inch TFT Display Screen

Product Details:

Place of Origin: CHINA
Brand Name: HST
Certification: CE ISO FCC
Model Number: HST-150R

Payment & Shipping Terms:

Minimum Order Quantity: 1 SET
Price: Negotiable
Packaging Details: Standard Export Wooden Package
Delivery Time: 7-20 days
Payment Terms: T/T, Western Union
Supply Ability: 500 sets/month
Contact Now
Detailed Product Description
Water Supply: Inner Water Supply Mode Exterior Material: Baked Painting Steel Or Stainless Steel(SUS304)
Temperature Range: -20 ~ 100 ℃ Ramping And Soaking Rate: -20℃ ↓ +100℃ Within 45 Min(no-load)
Humidity: 20%~98% Volume: 150 Or Customized

150L High temperature and constant heat climatic test chamber temperature humidity chamber



Product Overview



Able to accurately simulate a wide range of complicated natural environments, and is suitable for

reliability test in industrial products. Meet GB5170.2.3.5.6-95 standard requirements of environmental

testing equipment and test methods for the basic parameters of electric and electronic products under

the condition of humidity, low temperature, high temperature, and constant heat





Prouduct Application

Applicable to environmental adaptability and reliability test in such industrial units as electronics, electrical

appliance, battery, plastics, food, paper product, vehicle, metal, chemistry, building material, research

institution, inspection and quarantine bureau, university etc..





Prouduct Specifications



Chamber
Workspace volume IW 600× IH 600 × ID 460 mm
Exterior size IW 880× IH 1730× ID 1400mm
Temperature
Temperature range -40 ~ 150 ℃
Temp Deviation ±2.0℃
Temp Constancy ±0.5℃
Temp Uniformity ±0.5℃
Ramping and soaking rate

-40℃ ↓ +100℃ within 45 min(no-load)

+20℃ ↑ -40℃ within 60 min(no-load)

Humidity
Humidity range 20%R.H.~98%R.H
Control range
Humidity deviation ±2%RH
Humidity uniformity 3.0%RH
Humidity deviation ±2.0%RH
Chamber Structure

Overall structure and chamber was composed of three parts as below.

Insulation box, separate refrigeration units, and electrical control cabinet.

Insulation box

※ wall material: high-quality carbon steel with static color spray

※ inner wall material: SUS304 # matte stainless steel plate

※ Insulation materials: rigid polyurethane foam insulation layer + glass fiber.

Door Heating wire was installed at the door frames to prevent condensation at low temperatures.
Observation window With 2 sets 350 × 500mm (width × height) observation window, multi-hollow electric insulation coated glass prevent condensation effectively
Cable port Φ50mm*2 located on both sides(each*1) with rubber stopper and plastic cover
Lighting device 11W/AC220V *1 located on observation window
Water outlet hole Available for drain the condensate water
Sample holder Two layers of stainless steel sample holder.
Mobile Casters Mobile Casters *4 with foot cups
Electric control box Total power circuit breaker, over-temperature protection.
Water supply system Water pump automatic supply
Curve recording function Pt100
Controller KOMEG brand KM-5166 LCD Touch screen controller with PID control parameters setting
Display

Temperature and humidity settings (SV) Actual (PV) value can be displayed directly,

Execution of the program can display numbers, Paragraphs, remaining time and cycles, running time display,

Program editing and graphic curve display,

Fixed or program operation status display,

7-inch TFT display screen.

Resolution Temperature: + 0.01 ℃; Humidity: + 0.1%; Time: 1min
Setting range Temperature can be adjusted based on the working temp of the equipment(the upper limit +5 ℃, the lower limit -5 ℃)
Running mode programmable running ,constant running and booking boot
Setting mode Touch mode input
Communication interface

Data collection when connected to a computer

Can be used as monitoring and remote control system,

Multiple machines synchronization control available.

U disk Memory card 1G-8G available
Data collection RAM with battery protection settings, data can be saved, maximum historical data memory storage is 90 days (when the sampling time is 1min)
Power off memory Power recovery mode can be set as hot start, cold start and stop.
Pre-set function boot time can be set freely and machine runs automatically when turning on power
Software environment Windows2000 or Windows XP
Network Connection Can be connected to Ethernet, remote control function, data collection, can simultaneously control multiple machines.
Date and Time Fault alarm and causes handling prompts, power protection, the lower limit temperature protection, timer function (automatic start and automatic stop running), self-diagnostic function.





Environmental test chamber Standard



● GB-2423.1-89(IEC68-2-1)Test A:Low Temperature Test



● GB-2423.2-89(IEC68-2-2)Test B:High Temperature Test



● GJB360.8-87(MIL-STD.202F) High Temperature Life Test



● GBJl50.3(MIL-STD-810D) High Temperature Test



● GJBl50.4(MIL-STD-810D) Low Temperature Test



● GB2423.3-93(IEC68-2-3)Test Ca:Constant Heat Test



● GB2423.4-93(IEC68-2—30)Test Db:Damp Heat Alternative Test



● GJBl50.9-93(MIL-STD-810D) Damp Heat Test



Product Overview



Able to accurately simulate a wide range of complicated natural environments, and is suitable for

reliability test in industrial products. Meet GB5170.2.3.5.6-95 standard requirements of environmental

testing equipment and test methods for the basic parameters of electric and electronic products under

the condition of humidity, low temperature, high temperature, and constant heat.





Prouduct Application

Applicable to environmental adaptability and reliability test in such industrial units as electronics, electrical

appliance, battery, plastics, food, paper product, vehicle, metal, chemistry, building material, research

institution, inspection and quarantine bureau, university etc..
