Chamber Material: | 304 Stainleass Steel | High Temp Range: | +80℃~200°C |
---|---|---|---|
Low Temp Range: | -10°C~60°C; -10°C~-70°C; -10°C~-80°C; | Test Temp Range: | -40°C~150°C; -55°C~-150°C; -65°C~-150°C; |
Temperature Range:: | -40℃~150℃ (or Customized | Power Supply: | AC380V 50/60Hz |
Power: | Electronic | Recovery Time: | Within 3 Minutes |
High Light: | GJB360.7 Temperature Stability Chamber,SS304 Thermal Test Chamber,CE insulation Thermal Test Chamber |
Two box Hot impact industrial price thermal type test chamber temperature shock temperature Humidity Test Chamber
Cold and heat impact testing machine, used to test the material structure or composite material, under the instantaneous extremely high temperature and extremely low temperature under the continuous environment can bear the degree, in order to test in the shortest time its thermal expansion and contraction caused by chemical changes or physical damage. Applications include metals, plastics, rubber, electronics... And other materials can be used as the basis or reference for product improvement.
Characteristics:
1. The three boxes of equipment are divided into three parts: high temperature area, low temperature area and test area. The test products are placed in the test area. Relative to two boxes more room temperature function.
2. Using touch type graphic control operation interface, easy to operate the cylinder.
3. Impact mode: the temperature shall be imported into the test area by air circuit switching mode for cold and hot impact test.
4. When high temperature shock or low temperature shock, the maximum time can reach 999H, and the maximum cycle can reach 9999 times
5. The system can be used for automatic cycle engine or manual selective impact and can be used to set the start of zone 2 or zone 3 impact and cold and hot shock.
6. Binary cooling system is adopted for cooling, with quick cooling effect and water-cooled cooling mode.
7. Standard and test method: GJB150.5 temperature shock test; GJB360.7 temperature shock test; GB/2423.22 temperature shock test.
Standards:
1.GJB 150.5A-2009 Temperature Impact Test
2.GB/T 2424.13-2002 temperature shock test
3.GJB 360B-2009 Temperature Impact Test
4.GB/T 2423.2-2008 High temperature test method
5.GB/T 2423.1-2008/IEC 6008-2-1-2007 Low temperature test method
6.GB/T 10589-2008 Low temperature test chamber technical conditions
7.GB/T 11158-2008 high temperature test box technical condition specification
Specification:
Model |
DHS-CJ2-27 (A~C) |
DHS-CJ2-80 (A~C) |
DHS-CJ2-150 (A~C) |
DHS-CJ2-252 (A~C) |
DHS-CJ2-450 (A~C) |
Inner size W*H*D(cm) | 30*30*30 | 50*40*40 | 60*50*50 | 70*60*60 | 80*75*75 |
Outer size W*H*D(cm) | 140*180145 | 148*190*155 | 160*200*175 | 175*210*187 | 190*220*200 |
Temp range | (150ºC~A:-45ºC;B:-55ºC;C:-65ºC);( High temperature zone :+60ºC~+150ºC; Low temperature zone :-10ºC~-65ºC;) |
||||
Heating time (heat storage zone) | Reach RT~200ºC require around 35min | ||||
Cooling time (cool storage zone) Temperature recovery time / conversion time Temperature control accuracy/Distribution accuracy |
Reach RT~-70ºC require around 85min ≤5min / ≤10sec ±0.5ºC / ±2.0ºC |
||||
Defrost cycle | 1000times | ||||
Inner/Outer materia | The whole machine is SUS 304# stainless steel plate matte treatment, the inner box is stainless steel | ||||
Insulation materia | High temperature resistant high density ethyl chloroformate foam insulation material | ||||
System | P.I.D+S.S.R+Microcomputer balance temperature control system | ||||
Cooling system | Semi-closed double-stage compressor (water-cooled) / fully enclosed double-stage compressor (air-cooled) | ||||
Safety protection system | Fuseless switch, compressor high and low voltage protection switch, refrigerant high voltage protection switch, fault warning system, electronic alarm | ||||
Accessories | View window (special purchase type), two adjustable upper and lower compartments, energized line hole, caster, horizontal bracket | ||||
Power supply | AC 3 phase 380V 50HZ/60HZ |
Controller | 7 inch touch screen | ||||
Compressor | France/s "Tecumseh" Brand |
Weight (approximately) | 700Kg | 900Kg | 1200Kg | 1400Kg | 1900Kg |
More Details:
Features:
1.The constant temperature and humidity test box is mainly composed of control panel, distribution panel, insulation layer, air
supply fan, heater, humidifier and refrigeration unit. The main specifications can be divided into 6 standard sizes and 10
specifications under different conditions.
2.The controller can be connected to the computer through LAN interface. Users can design programs on the computer screen,
collect test data and records, call program execution, remote control machine switch and other functions.
3.The use of multi-wing air supply fan strong air circulation, to avoid any dead angle, so that indoor temperature and humidity
distribution is uniform.
4.Complete safety protection device, if abnormal conditions occur, the controller screen will automatically display the fault
status, cut off the power switch, and provide troubleshooting methods.
Production Process
Production Details
Factory Inspection
We control quality from the materials, electronic parts, controller,comppressor, solenoid valve, and many parts of the products.
Company Profile
BOTO GROUP is a professional manufacturer of various kinds of testing equipment over 20 years. BOTO products are widely used in paper products, packaging, ink printing, adhesive tapes, bags, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, and applicable to all scientific research units, quality inspection institutions and academic fields.
BOTO deals with customers from more than 150 countries and regions. Meanwhile, we are committed to cooperate with different dealers in different countries and regions in order to offer better service. Our mission is to help every customers establish testing labs to ensure the quality of their products.
Our company will continue to develop, innovate and keep faith. We combine with the international testing standards and the specific demands of customers that may establish a new banner in Chinese testing industry.
Main equipment
In the domestic market, we have many end customers, third-party testing institutions, research institutes, leading enterprises in different industries, and some agents. For the overseas market, we hope to find more general agents, distributors and importers to cooperate together.
Main market
The factory has the ability to calibrate, and the customer can also designate a ISO 17025 accredited third-party organization to calibrate and issue a calibration report.
Certification
The certificate is valid until June 17, 2024
Cooperative partners
BOTO ADVANTAGE
Customers photos
PACKAGE&DELIVERY:
1. Fully packed with PE film;
2. Wooden box;
3. Machine is fastened to the corners of the containers;
4. If export to European countries, the wooden box will be fumigated;
5. Customized package is available.
Q1: How can i get a quotation?
A1: Kindly provide us your details request (inner chamber size, temperature range, humidity range, power supply, product, etc.), leave us an inquiry or email and we will response promptly!
Q2: What's your temperature & humidity range?
A1: Our standards temperature range is -70℃~+180℃, 20%~98%RH.
We also can do Ultra low temperature to -190℃ .
Q3: What's your rate of heating & cooling?
A3: Our standards rate is average 3℃/min for heating, 2℃/min for cooling.
3℃/min,5℃/min,8℃/min,10℃/min,15℃/min linear or non-linear speed is available for us.
Q4: What's your warranty?
A4: 12 Months (Noted: free spares parts can be offered during warranty period, exclude consumables and man-made damages), life-time technical service
