Name: Direct Factory Delivery High Stability Constant Temperature And Humidity Controlled Environmental Test Chamber
Brand: BOTO GROUP LTD
SKU: BT-THS-100UA
Price: 120000 USD
Availability: InStock

Home > Products > Environmental Test Chambers >

Direct Factory Delivery High Stability Constant Temperature And Humidity Controlled Environmental Test Chamber

100L Environmental Test Chamber

Humidity Controlled Environmental Test Chamber

R404A Environmental Test Chamber

Place of Origin:

China

Brand Name:

BOTO

Certification:

CE ISO

Model Number:

BT-THS-100UA

Request A Quote

Direct Factory Delivery High Stability Constant Temperature And Humidity Controlled Environmental Test Chamber

Product Details

Workroom Dimensions(cm):

50*40*50

Inner Chamber Volume(v):

100L

Outer Diemension W*D*H(cm):

98*95*160

Packing Size:

113*110*175

G.W(kg):

360

Temperature Range:

A:-20℃-150℃ B:-40℃-150℃ C:-60℃-150℃ D:-70℃-150℃ E: -100-ambient (no Humidity For E)

Temperature Fluctuation:

≤ ±0.5℃ (standard) / ≤ ±0.2℃ (optional)

Temperature Evenness:

≤ ±2℃

Temperature Deviation:

≤ 1℃

Accuracy:

0.1℃ ,1.5%R.H (standard) /0.01℃ ,1.5%R.H (optional)

Humidity Range:

20%~98%R.H/ 10%~98%R.H (optional)

Humidity Deviation:

± 2%R.H

Temperature Rise Speed:

1.0℃~3.0℃/min

Temperature Down Speed:

0.7℃~1.2℃/min

Time Needed For Heating RT℃~150℃≤30min:

RT℃~150℃≤30min

Time Needed For Cooling:

RT℃~-40℃≤60min

The Machine Noise:

≤72dB(A)

Equipment Installed Power:

~3.25KW

MATERIAL INNER:

Material Inner Chamber:# SUS304 Stainless Steel

OUTER MATERIAL:

The Outer Wall:A3 Carbon Steel Plate With Plastic Spray/ #SUS304

Wind Cycling Way:

Centrifugal Fan-broadband Type Forced Air Ciruculation

Refrigeration Way:

Single Stage Compression Refrigeration

Refrigerater:

French Tecumseh

Refrigerats:

R404A USA Dupont Environment Protection Refrigerant

Heater:

Nickel Chorme Heating Wire Heater

Hunidifier:

Semi-closed Steam And Wet

Water Supplying Way:

Automatic Cycling Water Supply

Standard Accessories Parts:

1 Observe Window(double-deck Cavity Toughened Glass), 50mm Testing Hole, PL Inner Chamber, Partition Plate, Wet And Dry Bull Gauze, 3 Fues, 1 Power Line

Highlight:

100L Environmental Test Chamber

Humidity Controlled Environmental Test Chamber

R404A Environmental Test Chamber

Payment & Shipping Terms

Minimum Order Quantity

1set

Packaging Details

wooden case

Delivery Time

5-25 days

Payment Terms

L/C, T/T, Western Union

Supply Ability

30 Set/Sets per Month

Automotive Customizable Heat of oil test chamber with Japanese Mitsubishi PLC about 20~260C

Get Best Price

Made-To-Order Comprehensive Temperature,Humidity,Vibration Composite Test Chamber

Get Best Price

B-TH Walk-In High & Low Temperature Alternating Humidity Test Chamber For EV/Energy Storage

Get Best Price

High-Performance Made-To-Order PCT Benchtop High Pressure & High Humidity Environmental Test Chamber

Get Best Price

Contact Now

Product Description

Direct Factory Delivery High Stability Constant Temperature and Humidity Controlled Environmental Test Chamber

Products Description

Specifications

Temperature humidity chamber
	BT-THS-100UA	BT-THS-150UA	BT-THS-250UA	BT-THS-500UA	BT-THS-010UA
Workroom Dimensions(cm)	504050	505060	606070	807090	100100100
Inner chamber volume(v)	100L	150L	252L	504L	1000L
Outer Diemension WDH(cm)	9895160	98105170	108112180	128125200	148155210
Packing Size	113110175	113120185	123127195	133140215	163160225
G.W(kg)	360	390	450	480	620
Temperature Range	A:-20℃-150℃ B:-40℃-150℃ C:-60℃-150℃ D:-70℃-150℃ E: -100-ambient (no humidity for E)
Temperature Fluctuation	≤ ±0.5℃ (standard) / ≤ ±0.2℃ (optional)
Temperature Evenness	≤ ±2℃
Temperature Deviation	≤ 1℃
Accuracy	0.1℃ ,1.5%R.H (standard) /0.01℃ ,1.5%R.H (optional)
Humidity range	20%~98%R.H/ 10%~98%R.H (optional)
Humidity Deviation	± 2%R.H
Temperature Rise Speed	1.0℃~3.0℃/min
Temperature Down Speed	0.7℃~1.2℃/min
Time needed for heating	RT℃~150℃≤30min
Time needed for cooling	RT℃~-40℃≤60min
The machine noise	≤72dB(A)
Equipment installed power	~3.25KW	~3.55KW	~3.95KW	~5.5KW	~6.25KW
Material	Inner Chamber:# SUS304 stainless steel		The outer wall:A3 carbon steel plate with plastic spray/ #SUS304
Wind Cycling Way	Centrifugal fan-broadband type forced air ciruculation
Refrigeration Way	Single stage compression refrigeration
Refrigerater	French Tecumseh
Refrigerats	R404A USA Dupont environment protection refrigerant
Condesing Way	Air-cooled or water-cooled
Heater	Nickel Chorme Heating Wire Heater
Hunidifier	Semi-closed steam and wet
Water supplying way	Automatic cycling water supply
Standard Accessories parts	1 Observe window(double-deck cavity toughened glass), 50mm testing hole, PL inner chamber, partition plate, wet and dry bull gauze, 3 fues, 1 power line
