Environmental Temperature Humidity Climatic Test Chamber

Basic Information
Place of Origin: China
Brand Name: BOTO
Certification: CE ISO
Model Number: BT-NKHS-500-GDC
Minimum Order Quantity: 1set
Packaging Details: wooden case
Delivery Time: 5-25 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 200 Set/Sets per Month
Temperature Range:: 0℃-150℃ Fluctuation/Uniformity:: ±0.5℃/±2℃
Heating Rate:: 1℃/min-3℃/min Sensors:: Platinum Resistance. PT100Ω/MV
Water Supply System:: Humidification Water Supply Is Automatically Controlled Power:: Electronic
Humidity Range:: 20%R.H-98%R.H Cooling Rate:: 0.7℃/min-1℃/min
Humidification System:: All Stainless Steel Shallow Surface Evaporative Humidifier Usage Environment Temp:: 5℃~+30℃ ≤85%R.H
High Light:

Platinum Resistance Climatic Test Chamber

,

AC110V Climatic Test Chamber

,

98%RH Climatic Test Chamber

Environmental Temperature Humidity Climatic Test Chamber







Environmental Temperature Humidity Climatic Test Chamber

Factory direct and one-stop service





Product parameters

Temperature Range 0℃~150℃
Humidity range 20% R.H~98%R.H
Fluctuation/Uniformity ±0.5℃/±2℃
Heating rate 1℃/min~3℃/min
Cooling rate 0.7℃/min~1℃/min
Accuracy range Setting accuracy: temperature 0.1℃, humidity 1% R.H, indication accuracy: temperature 0.1℃, humidity 1% R.H
Sensors Platinum resistance. PT100Ω/MV
Humidification system External isolation type, all stainless steel shallow surface evaporative humidifier
Dehumidification system Using evaporator coil dew point temperature laminar flow contact dehumidification method
Water supply system Humidification water supply is automatically controlled. And can recycle the remaining water. Save water and reduce consumption
Circulation System Temperature-resistant and low-noise air-conditioning type motor. Multi-lobe centrifugal wind turbine
Standard configuration 1 set of illuminated glass window, 2 specimen holders, 1 test lead hole (25, 50, 100mm)
Security Protection Leakage, short circuit, over temperature, water shortage, motor overheating, compressor over pressure, overload, over current protection/controller power failure memory
Voltage AC110V/AV220V/AC380V/415V±10% 50±0.5Hz Three-phase five-wire system
Usage Environment temp 5℃~+30℃≤85%R.H





Product introduction



This product is simulated GB / T9596-2006 test box technical conditions GB / T9599-2009 low-temperature test box technical conditions GB / T 9592-2009 high and low-temperature test box technical conditions GB / T9159-2009 High temperature test box technical conditions

Mainly for aerospace, aviation, petroleum, chemical, military, automobile ( motorcycle ), ships, electronics, communications, and other scientific research and production units to provide temperature and humidity change environment, simulation test under the condition of temperature and humidity change environment loading simulation vibration adaptability test and the safety test of electronic components to provide reliability test, product screening.

All sizes of products can be customized.

Environmental Temperature Humidity Climatic Test Chamber 0

Temp and humidity range

Environmental Temperature Humidity Climatic Test Chamber 1

Environmental Temperature Humidity Climatic Test Chamber 2

Environmental Temperature Humidity Climatic Test Chamber 3

Company introduction

Environmental Temperature Humidity Climatic Test Chamber 4Environmental Temperature Humidity Climatic Test Chamber 5Environmental Temperature Humidity Climatic Test Chamber 6Environmental Temperature Humidity Climatic Test Chamber 7
