Temperature Stability Climatic Test Chamber

Basic Information
Place of Origin: China
Brand Name: BOTO
Certification: CE ISO
Model Number: BT- HJ-7121
Minimum Order Quantity: 1set
Packaging Details: wooden case
Delivery Time: IN STOCK
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100 Set/Sets per Month
Temp. Range: -20ºC~150ºC Power(KW): 4.5
Weight(KG): 150 Humidity Uniformity: ±3.0%R.H
Heat Up Time: -20ºC~+100ºC,within 35 Min Pull Down Time: +20ºC~-20ºC, Within 45 Min
Standard Accessories: Sight Window*1, Cable Port(portΦ50mm)*1, Shelves*2, Chamber Lamp*1, Power Cable *2m Safety Device (standard): No Fuse Breaker, Over Pressureover Heat And Over Current Protection For Compressor,
Control System: Balanced Temperature & Humidity Control System Humidity Range: 20~98%R.H
Temp. Constancy: ±0.5ºC Humidity Constancy: ±2.5%R.H
Temp. Uniformity: ±2.0ºC Interior Material: Stainless Steel Plate(SUS 304)
Exterior Material: Baked Painting Steel Or Stainless Steel(SUS304) Insulation Material: Rigid Polyurethane Foam And Glass Fiber Wool
Ambient Temp.: +5ºC~+35ºC Wiring Method: AC 380±10%50Hz ,3 Phase 4 Wires +Ground Wires
High Light:

4.5KW Environmental Test Chambers

,

98%RH Environmental Test Chambers

,

SUS304 Environmental Test Chambers

Temperature Stability Climatic Test Chamber

Product Description

New Design Temperature and Humdity Control Chamber Product Reliable Tester is designed for testing the capability of heat-endurance, cold-endurance, dryness-endurance, and humidity-endurance, suitable for quality control of the industries of electron, electrical equipment, vehicle ect.





Featuers

1. Delicate touch and excellent user experience;
2. Unique and compact design, topgrade appearance, stable performance and easy operation;
3. Can simulate a wide range of temperature and humidity environments;
4. Capable of testing large components, assemblies, and finished products;
5. Customized sizes and configurations avaible;
6. One year warranty
7. Visually attractive with large windows
8. Space-saving and Compact with optimized test chamber volumes
9. Powerful, suitable for a broad range of applications involving temperature and relative humidity



Technical Parameter Environmental Temperature and Humidity Chamber
Secifications ( at +20ºC room temp. Or+25ºC water temp with empty load)
Model BT-KMH-R series BT-KMH-L series BT-KMH-S series
36R 36L 36S
Temp. range -20ºC~150ºC -40 ºC~+150ºC -60ºC~+150ºC
Interior sizel W(mm) 300 300 300
H(mm) 400 400 400
D(mm) 300 300 300
Exterior size W(mm) 460 460 460
H(mm) 780 780 780
D(mm) 1020 1020 1020
Power(KW) 4.5 4.5 4.5
Weight(KG) 150 150 150
Humidity uniformity ±3.0%R.H ±3.0%R.H ±3.0%R.H
Heat up time -20ºC~+100ºC,within 35 min -40ºC~+100ºC, within 45 min -60ºC~+100ºC,within85 min
Pull down time +20ºC~-20ºC, within 45 min +20ºC~-40ºC , within 60 min +20ºC~-60ºC,within 80 min
Standard accessories Sight window*1, cable port(portΦ50mm)*1, shelves*2, chamber lamp*1, power cable *2m
Safety device (standard) No fuse breaker, over pressureover heat and over current protection for compressor,
Over temp. protect, over load protect of blower, dry heat protection
Control System Balanced Temperature & Humidity Control System
Refrigeration system Air Cooled
Hermetic compressor,Single stage refrigeration system
CFC-Free refrigerant(HFC-507/HFC-23)
Controller Panel:7-inch LCD Touch panel, Chinese or English display selectable
Operation model :Program or fix point running
Memory capacity :120programs,1200steps,
All repeat 999 cycles, part repeat 99 cycles
Humidity Range 20~98%R.H
Temp. constancy ±0.5ºC
Humidity constancy ±2.5%R.H
Temp. uniformity ±2.0ºC
Interior material Stainless Steel Plate(SUS 304)
Exterior material Baked Painting Steel Or Stainless steel(SUS304)
Insulation material Rigid polyurethane Foam and Glass Fiber Wool
Ambient Temp. +5ºC~+35ºC
Wiring method AC 380±10%50Hz ,3 phase 4 wires +Ground Wires
