Home > Products > Environmental Test Chambers >
Two-Box Type Hanging Basket Type For Thermal Shock Test Chamber Temperature And Humidity Testing Equipment

Two-Box Type Hanging Basket Type For Thermal Shock Test Chamber Temperature And Humidity Testing Equipment

Hanging Basket Environmental Test Chambers

SUS304 Thermal Shock Test Chamber

150L Thermal Test Chamber

Place of Origin:

China

Brand Name:

BOTO

Certification:

CE ISO

Model Number:

BT-2111

Contact Us
Request A Quote
Two-Box Type Hanging Basket Type For Thermal Shock Test Chamber Temperature And Humidity Testing Equipment
Two-Box Type Hanging Basket Type For Thermal Shock Test Chamber Temperature And Humidity Testing Equipment Two-Box Type Hanging Basket Type For Thermal Shock Test Chamber Temperature And Humidity Testing Equipment
Product Details
Inside Dimension WxHxD (cm):
40*50*40
Outside Dimension WxHxD (cm):
92*140*90
Temp Range:
-70°C ~~ +150°C
Humid Range:
20%~98%RH
Temp Accuracy:
±0.3°C
Humid Accuracy:
±2.5%RH
Temp Uniformity:
±1.5°C
Humid Uniformity:
±3%RH
Heating Up Speed:
3°C/min (average)
Heating Down Speed:
1°C/min (average)
Interior Material:
Stainless Steel Plate (SUS304#)
Exterior Material:
Stainless Steel Plate (SUS304#)
Insulation Material:
Rigid Polyurethane Foam Or Glass Wool
Refrigeration System:
Hermetic Compressor
Control System:
TEMI 880
Accessories:
Viewing Windows, Cable Port(dia.50mm), Chamber Lamp
Power:
3W,A C220V Or 5WAC380V
Highlight:

Hanging Basket Environmental Test Chambers

,

SUS304 Thermal Shock Test Chamber

,

150L Thermal Test Chamber

Payment & Shipping Terms
Minimum Order Quantity
1set
Packaging Details
wooden case
Delivery Time
5-25 days
Payment Terms
L/C, T/T
Supply Ability
100 Set/Sets per Month
RELATED PRODUCTS
Good price Automotive Customizable Heat of oil test chamber with Japanese Mitsubishi PLC about 20~260C online

Automotive Customizable Heat of oil test chamber with Japanese Mitsubishi PLC about 20~260C

Get Best Price
Good price Made-To-Order Comprehensive Temperature,Humidity,Vibration Composite Test Chamber online

Made-To-Order Comprehensive Temperature,Humidity,Vibration Composite Test Chamber

Get Best Price
Good price B-TH Walk-In High & Low Temperature Alternating Humidity Test Chamber For EV/Energy Storage online

B-TH Walk-In High & Low Temperature Alternating Humidity Test Chamber For EV/Energy Storage

Get Best Price
Good price High-Performance Made-To-Order PCT Benchtop High Pressure & High Humidity Environmental Test Chamber online

High-Performance Made-To-Order PCT Benchtop High Pressure & High Humidity Environmental Test Chamber

Get Best Price
Contact Us
Contact Now
Product Description

Two-box Type/hanging Basket Type For Thermal Shock Test Chamber Temperature And Humidity Testing Equipment



Product Description

This machine for testing functions of heat endurance, cold-endurance, drought-endurance, wet-endurance suitable for quality control of factories of electronics, electronics, electric appliance, foodstuffs, automobiles, metal, chemicals plywood and Two-box type/hanging basket type for thermal shock test chamber etc.

Specifications:



Model 80L 150L 225L 408L 800L 1000L
Inside dimension WxHxD (cm) 40*50*40 50*60*50 50*75*60 60*85*80 100*100*80 100*100*100
Outside dimension WxHxD (cm) 92*140*90 105*150*110 105*165*120 115*175*140 160*190*160 160*190*160
Temp Range -70°C ~~ +150°C
Humid Range 20%~98%RH
Temp Accuracy ±0.3°C
Humid Accuracy ±2.5%RH
Temp Uniformity ±1.5°C
Humid Uniformity ±3%RH
Heating Up Speed 3°C/min (average)
Heating Down Speed 1°C/min (average)
Interior Material Stainless Steel Plate (SUS304#)
Exterior Material Stainless Steel Plate (SUS304#)
Insulation Material Rigid polyurethane foam or glass wool
Refrigeration System Hermetic Compressor
Protection Devices Fuse-free switch, overloading protection switch for compressor, high and low voltage coolant protection switch, over-humidity and over-temperature protection switch, fuses, failure warning system
Control System TEMI 880
Accessories Viewing Windows, Cable Port(dia.50mm), Chamber lamp
Power 3W,A C220V or 5WAC380V



Our Services



Have independent production base plant.

Strong design and manufacturing capabilities.

Strong technical force and high-quality after-sales service.

Efficient after-sales service team.

A number of certification qualifications.

Factory outlets, so that customers benefit the most.

Two-Box Type Hanging Basket Type For Thermal Shock Test Chamber Temperature And Humidity Testing Equipment 0

Two-Box Type Hanging Basket Type For Thermal Shock Test Chamber Temperature And Humidity Testing Equipment 1



PRODUCTION LINE MACHINE

Two-Box Type Hanging Basket Type For Thermal Shock Test Chamber Temperature And Humidity Testing Equipment 2Two-Box Type Hanging Basket Type For Thermal Shock Test Chamber Temperature And Humidity Testing Equipment 3



CERTIFICATIONS



Two-Box Type Hanging Basket Type For Thermal Shock Test Chamber Temperature And Humidity Testing Equipment 4Two-Box Type Hanging Basket Type For Thermal Shock Test Chamber Temperature And Humidity Testing Equipment 5



Cooperative partners

Two-Box Type Hanging Basket Type For Thermal Shock Test Chamber Temperature And Humidity Testing Equipment 6
