-40C~150C Two Zone Under Alternating High-Low Temperature Testing Environment Hot Cold Thermal Shock Test Chamber

Basic Information
Place of Origin: China
Brand Name: BOTO
Certification: CE ISO
Model Number: BOTO
Minimum Order Quantity: 1set
Price: Negotiated
Packaging Details: wooden case
Delivery Time: 5-25 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100 Set/Sets per Month
Refrigerant:: R404A / R23 Power:: Electronic
Temperature Deviation:: Less Than ±2°C Power Supply:: 380V, 50Hz
Temperature Range:: -40~150C/-60~150C Temperature Conversion Time:: Less Than 10S
Materia:: SUS#304 Stainless Steel Plate Setting Range:: -100.00~200.00°C
Cooling Method:: Water Cooling
High Light:

SUS304 Thermal Shock Test Chamber

,

R404A Thermal Shock Test Chamber

,

Water Cooling Thermal Shock Test Chamber

-40C~150C Two Zone Under Alternating high-low Temperature Testing Environment Hot Cold Thermal Shock Test Chamber



Product Description

BOTO Thermal shock test chamber is used to test the bearing extent of the material structures and composite material in an instant and continuous high temperature and extremely low temperature environment, that is in the shortest time to test its thermal expansion and contraction caused by chemical change or physical harm, which is widely used in metal, plastic, rubber, electronics and other materials and it can be used as an important reference for improving product quality. It meets the standard of MTL, IEC, JIS, GJB...

Specifications

Can be customized:

Inner size(mm) 400×350×300
Temperature range High temperature chamber:RT~+150°C Low temperature:RT~-60°C
Temperature deviation Less than ±2°C
Temperature conversion time Less than 10S
Temperature recovery time Less than 5min
Material

External material: SUS#304 Stainless steel plate

Internal material: SUS#304 Stainless steel plate

Coolting system

Water-cooled or air-cooled,

Tecumseh compressor in France,

Environment friendly refrigerant

Controllor Programmable temperature controllor imported from Japan
Temperature sensor PT 100 *3
Setting range

Temperature: -100.00+200.00°C

/ Time: OH1M ~ 9999H 59M

/ Cycle: 10000 cycle

Resolution Temperature: 0.01°C / Tim: 1min
Output mode PID + PWM + SSR control method
Simulated load IC (kg) 3.5kg
Standard accessories Cable hole, lighting equipment
Cooling system Water-cooled/air-filled type
Power AC380V/50HZ Three-phase four-wire ac power
Additional features

The outlet and return it checks for taste known control

/CM BUS (RS-485) remote monitoring management system

/Ln2 liquid nitrogen rapid cooling control device

Remarks

It can be customiazed according to customer demands.

Technology index refer to product description.Delivery time within 45 days.

Product Effects

Liyi -40C~150C Two Zone Under Alternating high-low Temperature Testing Environment Hot Cold Thermal Shock Test ChamberLiyi -40C~150C Two Zone Under Alternating high-low Temperature Testing Environment Hot Cold Thermal Shock Test Chamber

Liyi -40C~150C Two Zone Under Alternating high-low Temperature Testing Environment Hot Cold Thermal Shock Test Chamber



Company information



BOTO GROUP Ltd. is a private enterprise integrating R&D, production, OEM and sales of scientific and technological equipment manufacturing. Proficient in the production, development and upgrading of various non-standard instruments and automatic instruments. The factory covers an area of 26,666 square meters, headquartered in Shanghai, has several offices in China, the factory annual output of about 2000 sets of equipment. Since the establishment of the company, the company is committed to providing customers with quality products and services, and has been praised by customers.



-40C~150C Two Zone Under Alternating High-Low Temperature Testing Environment Hot Cold Thermal Shock Test Chamber 3

Factory tour



-40C~150C Two Zone Under Alternating High-Low Temperature Testing Environment Hot Cold Thermal Shock Test Chamber 4



Production Details



-40C~150C Two Zone Under Alternating High-Low Temperature Testing Environment Hot Cold Thermal Shock Test Chamber 5



-40C~150C Two Zone Under Alternating High-Low Temperature Testing Environment Hot Cold Thermal Shock Test Chamber 6



Workshop machine:



-40C~150C Two Zone Under Alternating High-Low Temperature Testing Environment Hot Cold Thermal Shock Test Chamber 7



Main equipment include:

-40C~150C Two Zone Under Alternating High-Low Temperature Testing Environment Hot Cold Thermal Shock Test Chamber 8



In the domestic market, we have many end customers, third-party testing institutions, research institutes, leading enterprises in different industries, and some agents. For the overseas market, we hope to find more general agents, distributors and importers to cooperate together.



Main market:



-40C~150C Two Zone Under Alternating High-Low Temperature Testing Environment Hot Cold Thermal Shock Test Chamber 9



The factory has the ability to calibrate, and the customer can also designate a third party organization to calibrate and issue a calibration report.





Certification



-40C~150C Two Zone Under Alternating High-Low Temperature Testing Environment Hot Cold Thermal Shock Test Chamber 10









-40C~150C Two Zone Under Alternating High-Low Temperature Testing Environment Hot Cold Thermal Shock Test Chamber 11

BOTO ADVANTAGE



-40C~150C Two Zone Under Alternating High-Low Temperature Testing Environment Hot Cold Thermal Shock Test Chamber 12



Customers photos

-40C~150C Two Zone Under Alternating High-Low Temperature Testing Environment Hot Cold Thermal Shock Test Chamber 13

-40C~150C Two Zone Under Alternating High-Low Temperature Testing Environment Hot Cold Thermal Shock Test Chamber 14

-40C~150C Two Zone Under Alternating High-Low Temperature Testing Environment Hot Cold Thermal Shock Test Chamber 15

-40C~150C Two Zone Under Alternating High-Low Temperature Testing Environment Hot Cold Thermal Shock Test Chamber 16

-40C~150C Two Zone Under Alternating High-Low Temperature Testing Environment Hot Cold Thermal Shock Test Chamber 17

Our Services

During the whole business process, we offer Consultative Selling service.

1) Customer inquiry process:

Discussing testing requirements and technical details, suggested suitable products to customer to confirm. Then quote most suitable price according to customer requirements.

2) Specifications customize process:

Drawing related drawings to confirm with customer for customized requirements. Offer reference photos to show the products appearance. Then, confirm the final solution and confirm final price with customer.

3) Production and delivery process:

We will produce the machines according to confirmed PO requirements. Offering photos to show production process.

After finish production, offer photos to customer to confirm again with the machine. Then do own factory calibration or third party calibration(as customer requirements). Check and test all the details and then arrange packing.

Deliver the products in confirmed shipping time and inform customer.

4) Installation and after sale service:

Defines installing those products in the field and providing after-sales support.
