| Place of Origin: | China |
|---|---|
| Brand Name: | BOTO |
| Certification: | CE ISO |
| Model Number: | BT-Y-2000 |
| Minimum Order Quantity: | 1set |
| Price: | Negotiated |
| Packaging Details: | wooden case |
| Delivery Time: | 5-25 days |
| Payment Terms: | L/C, T/T, |
| Supply Ability: | 100 Set/Sets per Month |
| Power:: | Hydraulic | Product Name:: | Compression Tester Compress Machine |
|---|---|---|---|
| Power Supply:: | AC 3 Phase 380V/220v 60/50Hz | Measuring Range:: | 4%-100% FS |
| Piston Stroke:: | 50mm | Test Space Adjusting Way:: | Electric Ball Screw Adjusting |
| Display:: | Digital Display | Control:: | Manual Control Loading Process |
| High Light: | 1000KN Cube Compression Testing Machine,Metallurgy Compression Testing Machine,50mm Piston Stroke Compression Tester |
||
1000kn 2000kN/3000kN YES-D Concrete Cube Compression Testing Machine/Electric Control Compression Tester
1. Application
This compression testing machine mainly used for concrete rupture strength testing, cement, plastic sand, and red brick building materials compression resist testing. Widely used in metallurgy, building materials, space flight and aviation, colleges and universities, R&D institution lines. The test operation and data processing meets standard requirements.
Feature:The test data is not only could displayed on LCD directly, but also could be displayed on computer screen.
Main Specifications
| Model | BT-Y-1000 | BT-Y-2000 | BT-Y-3000 |
| Max. load | 1000KN /100Ton | 2000kN/200Ton | 3000kN/300Ton |
| Machine Class | 1 class | ||
| Range of test force | 4% ~100%FS | ||
| Testing space adjust method | Manual adjust | ||
| Indicating value accuracy | ±1% | ||
| Piston stroke | 30mm | 50 | |
| Diameter of Piston | 250mm | 300 | |
| Distance between platens | 320mm | 400mm | |
| Upper platen size | 220*250mm (Can be customized) | 300x300mm | |
| Display | LCD screen display | ||
| Power supply | 0.75KW, AC380V/50Hz/3 phase(can be customized) | ||
| Size | 880*480*1400 mm | 1000x500x1450mm | |
| Weight | 600kg | 1000Kg | |
| Power | 380V/220V / 0.75KW | ||
