Xenon Lamp Aging Resistance Test Chamber Accelerated Weathering Tester

Basic Information
Place of Origin: China
Brand Name: BOTO
Certification: CE ISO
Model Number: BT-2022
Minimum Order Quantity: 1set
Price: Negotiated
Packaging Details: wooden case
Delivery Time: 5-25 days
Payment Terms: T/T
Supply Ability: 100 Set/Sets per Month Accelerated Weathering Tester
Certificate:: ISO/CE/FCC/3C/ROHS,etc. Humidity Range:: ABOUT 65~98%R.H
Temperature Range:: Rt+10°C ~80°C Raining Time:: 1~9999min, Adjustable
Raining Period:: 1~240min, Gap Adjustable Wavelength:: 290nm~800nm(60w/m2)
Irradiation Light Source:: Full-spectrum Xenon Lamp Shipment Date:: Short Leadtime
High Light:

SUS304 Xenon Aging Test Chamber

,

AC380V Xenon Aging Test Chamber

,

GB12831-86 Xenon Aging Test Chamber



Xenon Lamp Aging Resistance Test Chamber Accelerated Weathering Tester





Product Description

Equipment summary:

Xenon lamp aging testing chamber is a comprehensive climate testing machine, in addition to climatic aging test, the lightfastness of materials can be carried out to test, polymer materials exposed at simulated sunlight. It simulates thelight, temperature, rainfall, condensing, humidity to test the materials;it can beused for choosing new materials,improving existing materials, or assessment of change in material composition.



Technical parameter:

Model ZME-2011
Testing room D×W×H 500*600*500mm
Index Temperature range RT+10℃~80℃
Humidity range 65~98%R·H
Spray time 1~9999min, adjustable
Spray cycle 1-240min, interval adjustable
spectral wavelength 290nm~800nm(60w/m2)
light source xenon lamp(air-cooled)
Xenon lamp power 1kw,6kw(longevity:1600H)

Temperature

and humidity

control

Time controller Import controller from Moeller
Accurate range Temperature: ±0.1℃,/ humidity: ±0.1℃R·H
Sensor Platinum resistance Pt100Ω/mv
Heating system Independent system, nickel chromium alloy electric heating type heater
Humidity system stainless steel, external Isolated humidifier
Blackboard temperature Bimetal thermometer blackboard 55℃~75℃
Water supply

Humidification water supply with automatic control, xenon lamp

cooled by water recycling

Temperature controller Import controller
humidity Irradiation: 30%~65%RH darkly: up to 90%RH
Cycle system low-noise air-conditioning-type motors, multi-leaf-type centrifugal wind wheel
Material Outside material Advanced spray color plate /SUS304 stainless steel
Inside material SUS304 stainless steel
Sample holder material SUS304 stainless steel
insulation High and low temperature aging of silicone rubber
Standard

a set of radiation-proof glass window, dynamic testing sample shelf 1,

xenon lamp tube 2

Protector Leakage, short circuit, over-temperature, water shortages, motor overheating, over-current protection.
Power AC380V±10% 50±0.5HZ , Three-phase five-wire system
Environmental temperature ±5℃~+30℃ ≤85%R·H



Equipment safety protection device:

1. Power overload, short circuit protection
2. ground protection
3. over temperature protection
4. Water shortage protection
5. In order to protect the equipment,All alarm will automatically cut off power supply, and with audible reminder



Operating conditions:

1. Temperature: 15℃~35℃
2. Relative humidity: less than 85%RH
3. Without strong vibration and strong electromagnetic field
4. Without high concentration of dust and corrosive materials in round field
5. No direct sunlight or other sources of heat radiation directly
6. Without a strong airflow around,when need forced air flow around,air should not be blown directly to the body
7. Test cases should be placed stably, level
8. The sides of the test chamber should keep a certain distance, convenient maintenance operation
9. Installation site well ventilated
10. Ground Benign





Detailed Images
Xenon Lamp Aging Resistance Test Chamber Accelerated Weathering Tester 0

Corresponding standard:
GB12831-86 Vulcanized rubber artificial climate (xenon lamp) Aging Test Method

GB/T1644.2-1999Plastics laboratory light exposure test method

GB/T8427-89 textile color fastness test, resistance to artificial light fastness xenon arc

GB/T8430-98 textile color fastness test, resistance to artificial light fastness xenon arc

GB/T1865-97 Paints, varnishes, artificial weather aging and artificial radiation exposure

GB/T16991-97 textile color fastness test

GB/T5137.3-96 simulated climate test method of resistant to radiation, heat, humidity, burning
GB/T16259-96 color building materials, artificial climate accelerated aging test method.

GB/T2423.24-95 Electronic and Electrical Products Environmental Testing Part II: test method, testing

SQSimulation of solar radiation on the ground





Company profile



BOTO GROUP Ltd. is a private enterprise integrating r&d, production, OEM and sales of scientific and technological equipment manufacturing. Proficient in the production, development and upgrading of various non-standard instruments and automatic instruments. The factory covers an area of 26,666 square meters, headquartered in Shanghai, has several offices in China, the factory annual output of about 2000 sets of equipment. Since the establishment of the company, the company is committed to providing customers with quality products and services, and has been praised by customers.



Xenon Lamp Aging Resistance Test Chamber Accelerated Weathering Tester 1



In the domestic market, we have many end customers, third-party testing institutions, research institutes, leading enterprises in different industries, and some agents. For the overseas market, we hope to find more general agents, distributors and importers to cooperate together.



Xenon Lamp Aging Resistance Test Chamber Accelerated Weathering Tester 2





The factory has the ability to calibrate, and the customer can also designate a third party organization to calibrate and issue a calibration report.
