Spot Welding Machine 35KVA/63KVA/75KVA 35% Duty Cycle

Spot Welding Machine 35KVA/63KVA/75KVA 35% Duty Cycle
Spot Welding Machine 35KVA/63KVA/75KVA 35% Duty Cycle Spot Welding Machine 35KVA/63KVA/75KVA 35% Duty Cycle Spot Welding Machine 35KVA/63KVA/75KVA 35% Duty Cycle
Basic Information
Place of Origin: China
Brand Name: BOTO
Certification: CE ISO
Minimum Order Quantity: 1set
Price: 2000-2600USD
Packaging Details: Wooden case
Delivery Time: 1-25 days,to be negotiated
Payment Terms: T/T, L/C
Supply Ability: 200 Set/Sets per Month 200sets
Contact Now
Rated Capacity:: 35KVA/63KVA/75KVA Rated Duty Cycle:: 35%
Max. Welding Thickness:: 3+3/3.5+3.5/4+4 Key Selling Points:: Easy To Operate
Certification:: CCC,ISO9001 Weight (KG):: 300 KG
Warranty:: 1 Year Warranty Service:: Video Technical Support
After Warranty Service:: Online Support After Service:: Spare Parts
Highlight:

Straight Type Spot Welding Machine

,

Steel Spot Welding Machine 63KVA

,

Shock Resistant Spot Welder

Spot Welding Machine 35KVA/63KVA/75KVA 35% Duty Cycle



Product Description

spot welding machine Features:

1) Staight type pressing structure, high welding speed. Electro valve and gas cylinder are connected directle, increasing responding and apot welding sppeed,reducing air flow cost
2) Perfect pressurization speed ajustment, descending speed of machine head pressurization can be adjusted at will, which softerns impact and lowers noise when pressurize the workpiece
4) Reliable circular water cooling system, reducing cooling water cost substantially
5) High strength steel performance, shock resistant, firm.
6) High power SCR element is adjusted for main loop, stable and reliable


Main parameter (DTN-35/63/75):
1) Rated input voltage (V): 380
2) Rated frequency (Hz): 50/60
3) Rated input capacity (kVA): 35/63/75
4) Duty cycle (%): 20
5) Throat depth (mm): 450/500/500
6) Max. pressurization force (N): 6000
7) Electrode stroke (mm): 75/80/80
8) Welding thickness (carbon steel): 3+3/3.5+3.5/4+4
9) Weight: 220/300/320kg.
