Salt Spray Corrosion Test Chamber China Factory ASTM B-117 Standard Chamber

Basic Information
Place of Origin: China
Brand Name: BOTO
Certification: ISO/PED/TUV/SGS/LR/BV
Model Number: B-SST-60
Minimum Order Quantity: 1pcs
Price: Negotiation
Packaging Details: wooden case
Delivery Time: 15-30 working days
Payment Terms: T/T
Supply Ability: 10000 PC Per Month
Name: Salt Spray Coeeosion Test Chamber Material: Coeeosion-resistant Polymer
Power Source: AC:220V 50HZ Saturated Air Pressure: 0.8~2.0±0.01
Usage: Universal Testing Machine,Salt Spray Tester Standard: IEC60068-2-1
High Light:

ASTM B117 Salt Spray Test Chamber

,

Salt Spray Corrosion Test Chamber 50HZ

,

Iron Salt Spray Corrosion Test Chamber

Salt Spray Coeeosion Test Chamber China Factory ASTM B-117 Standard Chamber



BOTO salt spray test machine can determine the corrosion resistance of iron metal or the iron metal inorganic film or organic film test, such as: electroplating, anode processing, conversion coating, painting, ect.



BOTO salt spray test machine is an accelerated corrosion test that produces a corrosive attack to the coated samples in order to predict its suitability in use as a protective finish. The appearance of corrosion products (oxides) is evaluated after a period of time. Test duration depends on the corrosion resistance of the coating; the more corrosion resistant the coating is, the longer the period in testing without showing signs of corrosion. Different coatings have different behaviour in salt spray test and consequently, test duration will differ from one type of coating to another.

Salt Spray Corrosion Test Chamber China Factory ASTM B-117 Standard Chamber 0

Product Description

The Salt Spray Combined Climate Tester is to test: If surface of different material can adopt the corrosion resistance, as well as changes in temperature and humidity after the plating, anodic treatment, spraying, anti-rust oil and other anti-corrosion treatment. This machine is designed to test the influence of salt pollution that might accelerate the corrosion on the metal material outdoors. The device contains the circulation of the sample to the salt fog, dry, hot and humid environment test method.

Salt Spray Corrosion Test Chamber China Factory ASTM B-117 Standard Chamber 1

Salt Spray Corrosion Test Chamber China Factory ASTM B-117 Standard Chamber 2

Corresponding Standard : 1. GB/T 2423.17-1993 salt spray test 2. GB/T 2423.18-2000 salt spray test 3. GB/T 10125-1997 salt spray test 4. ASTM.B117-97 salt spray test 5. JIS H8502 salt spray test 6. IEC68-2-11 salt spray test 7. IEC68-2-52 1996 salt spray test 8. GB.10587-89 salt spray test 9. CNS.4158 salt spray test 10. CNS.4159 CASS Accelerated acetic acid copper salt spray test 11. GB/T 12967.3-91 CASS Accelerated acetic acid copper salt spray test



Model BT-609-60 BT-609-90 BT-609-120 BT-609-150 BT-609-200
Design standard

GB/T 10587-2006, GB/T 10125-1997,

JIS-D0201, H8502, H8610, K5400, Z2371

Test chamber capacity(L) 108L 270L 600L 750L 1000L
Temperature Test chamber NSS.ACSS 35°C±1°C/CASS 50°C±1°C
Saturated air cylinder NSS.ACSS 47°C±1°C/CASS 63°C±1°C

Test chamber size

L×W×D(cm)



60*45*40



90*60*50



1200*1000*500



1500*1000*500



2000*1000*500

Max capacity of test liquid(L) 15 25 40 40 40
Power AC220V,10A AC220V,15A AC220V,30A

Detail Images

Salt Spray Corrosion Test Chamber China Factory ASTM B-117 Standard Chamber 3

Salt Spray Corrosion Test Chamber China Factory ASTM B-117 Standard Chamber 4

Our Services & Strength:

1. 10 years manufacture in testing machine

2. 5 years alibaba supplier

3. 100% QC inspection before shipment

4. 12 months warranty 5. Product Certificated by CE



OUR CERTIFICATES




packing:wooden case

Salt Spray Corrosion Test Chamber China Factory ASTM B-117 Standard Chamber 6
