Basic Information
Place of Origin: China
Brand Name: BOTO
Certification: MIL STD GB JIS JEDEC IEC ISO
Model Number: B-T-120(A~E)
Minimum Order Quantity: 1 PCS
Price: Negotiable
Packaging Details: wooden case
Delivery Time: 15days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000PC/Month
Contact Now
Name: Rapid Temperature Test Chamber Model: B-T-120(A~E)
Interior: SUS#304Stainless Steel Plate Exterior: Coating Or SUS#304Stainless Steel Plate
Power Source: AV：220V/380V 50/60Hz Power（KW）: 1KW~2KW
Temp Range: -70℃~180℃(100℃) Heat-up Time: 1℃-15℃／min
Pull Down Time: 1℃-15℃／min Temp Fluctudtiont: ±0.5℃

Environmental Test Chambers Rapid Temperature Test Chamber ISO Program Setting NABMAT-9492



Description:

In order to ensure the cooling rate of the test chamber and the minimum temperature requirements, the test chamber uses a set of Taikang fully enclosed compressor composed of binary overlapping air cooling refrigeration system. The overlapping refrigeration system consists of a high temperature refrigeration cycle and a low temperature refrigeration cycle, and its connecting vessel is the evaporative condenser. The evaporative condenser also plays the role of energy transfer, transferring the heat energy in the working room through the two-stage refrigeration system to achieve the purpose of long temperature. Refrigeration system design application of energy regulation technology, an effective treatment can ensure that in the normal operation of the refrigeration unit and the refrigeration system of energy consumption and cooling capacity for effective regulation, so that the refrigeration system operating costs and failure rate down to a more economic state.

Environmental Test Chambers Rapid Temperature Test Chamber ISO Program Setting NABMAT-9492 0

Environmental Test Chambers Rapid Temperature Test Chamber ISO Program Setting NABMAT-9492 1

This test equipment is suitable for:
Electrical, electronic products, components, components and materials are stored in high and low temperature environments

Adaptability tests for storage, transportation and use.



Manufacturer:

Model dry heat B-T-80(A-E) B-T-120(A~E) B-T-225(A~E) B-T-504(A~E) B-T-1000(A~E)
damp and ho B-TH-80(A-E) B-T-120(A~E) B-T-225(A~E) B-T-504(A~E) B-T-1000(A~E)
 Internal Dim (CM) 40x50x40 45x60x45 60x75x50 70x90x80 100x100x100
 External Dim(CM) 75x203x203 75X189X110 90X177X130 100X180X103 130X190X123
 Relative Humidity 20％-98％RH
Temp Range -70℃~180℃(100℃) (A:0℃ B:-20℃ C:-40℃ D:-60℃ E:-70℃)
heat-up time
1℃-15℃／min
Pull down time 1℃-15℃／min
Temp Fluctudtiont ±0.5℃
Temp Uniformity ±1.0℃
Temp&Humi.Deviation ±1.0℃/±3.0℃RH
 Interior SUS#304Stainless steel plate
Exterior Coating or SUS#304Stainless steel plate
 Power Source AV:220V/380V 50/60Hz
Power(KW) The technical proposal shall prevail

Our company:

Environmental Test Chambers Rapid Temperature Test Chamber ISO Program Setting NABMAT-9492 2

Environmental Test Chambers Rapid Temperature Test Chamber ISO Program Setting NABMAT-9492 3

Environmental Test Chambers Rapid Temperature Test Chamber ISO Program Setting NABMAT-9492 4

Environmental Test Chambers Rapid Temperature Test Chamber ISO Program Setting NABMAT-9492 5

FAQ:

Do you accept customization service?

Yes, of course, we can not only offer standard machines, but also customized machines according to your request. Don’t hesitate to tell us your requirement, we will try our best to meet your needs.

How about your warranty?

Generally, our warranty is one year. Within the warranty period, we can offer technique support and part parts change, necessarily, our engineers may go to your place for better service.

How about the packing for machine, is it safely protected during transportation?

Our machine is packed by standard export wooden box, it won’t be damaged. We’ve delivered many testing machines abroad by sea or by air without damage.

Packing/Shipping:



Environmental Test Chambers Rapid Temperature Test Chamber ISO Program Setting NABMAT-9492 6

Environmental Test Chambers Rapid Temperature Test Chamber ISO Program Setting NABMAT-9492 7



Our Services



As leading manufacturer,we guarantee below:
100% Competitive price we are the original manufacturer of densimeter for years, the large scale production make our products more competitive, that’s the reason we are very confident to offer the most possible competitive price for the same level testing instruments in the world.
High quality standards we have the powerful professional researching and technology team to support quality;Our quality has been proved by the good market reaction for years;Our product are built to meet the industrial standards and global standards;Every instrument get checked and approved by our QC before delivery.
Faultless service we have the professional customer service team to provide the one to one service for you;we can help you to enjoy the one-stop service without any worries;we have the completed after-sales service policy and quality insurance policy;we guarantee instruments for one year and life-long maintenance(Gold Purity Tester for two years)
Efficient logistics we have the stable partner to help us to deliver the goods to the any corner of the worldwide shortly.Air shipment;International express:DHL/UPS/FEDEX/TNT(5 days to 7 days)
OEM service We are the original manufacturer of densimeter,that is verified by the third party and on site;We can provide you OEM service and print your logo on the instruments.
