Basic Information
Place of Origin: China
Brand Name: BOTO
Certification: MIL STD GB JIS JEDEC IEC ISO
Model Number: DHG-9030A 101A-0S
Minimum Order Quantity: 1PCS
Price: Discussible
Packaging Details: wooden case
Delivery Time: 15days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000PC/Month
Contact Now
Model: DHG-9030A 101A-0S Internal: 350*350*350
External Dim: 480*470*685 Low Temp Range: -10℃--60℃
Test Temp Rang: -40℃-150℃ HighTemp Rang: ＋80℃～200℃
Interior: SUS#304Stainless Steel Plate Exterior: Coating Or SUS#304Stainless Steel Plate
Temperature Fluctuation: ±0.3℃ Temperature Departure: ±1.0℃
Highlight:

Floor Standing High Temperature Chamber

,

SUS304 Environmental High Temperature Chamber

,

High Temperature Climatic Chamber 101A-0S

Climatic Chamber Environmental Test Chambers High Temperature Chamber High-Performance DHG-9030A 101A-0S Test Machine



Introduction:

High Temperature Oven can provide a stable test space for preheating, drying, changes about physics and chemistry testing . It supplies precision temperature controller with high stability of platinum resistance to temperature that makes temperature well-distribution.Applications:Plastic Rubber Materials,Adhesive Tape,Food,Pharm,Daily-used chemical,etc.
High temperature test chamber (high and low temperature test chamber) is one of the simulation of climate environment test equipment, suitable for various products or materials under high temperature conditions performance test. It can be used in the laboratory of scientific research units, product quality control centers and industrial and mining enterprises. Digital display temperature control, PID self-regulation, and has the function of overtemperature protection.

This product is suitable for testing according to the national standard GB/T2423.2 "Environmental Test of Electrical and electronic products Test B: High temperature test Method". Meet GB/T2423.2 test method standard requirements.


Description

Applications:

High Temperature Thermal Aging Test Chamber NuOven LS-100A is used in laboratory, hospitals and industry.

Main Features

1.Floor standing high temperature thermal aging chamber

2.Heating on the back

3.Horizontal force convection with reliable fan to assure chamber temperature uniformity

4.Stainless steel working chamber

5.Power coated steel housing

6.Dual-layer toughened glass observation window

7.Rotary plate (10rpm) and illumination, convenient use in laboratory

8.Thermal controller with high-peed, high-performance CPU chip

9.High-sensitivity and high precision Pt resistance sensor

10.Preset programmed control with timing range up to 99 hours for power-on, power-off and workin

Climatic Environmental Test Chambers High Temperature Chamber High-Performance DHG-9030A 101A-0S Test Machine 0

Climatic Environmental Test Chambers High Temperature Chamber High-Performance DHG-9030A 101A-0S Test Machine 1

Climatic Environmental Test Chambers High Temperature Chamber High-Performance DHG-9030A 101A-0S Test Machine 2

Climatic Environmental Test Chambers High Temperature Chamber High-Performance DHG-9030A 101A-0S Test Machine 3

product feature:

SECC steel plate and fine powder baking paint are used. SUS stainless steel new high temperature resistant long shaft motor turbofan high temperature resistant fiber overtemperature protection: strong load automatic power off system circulation mode: forced horizontal air supply circulation heating mode: PID+S.S.R Temperature range: room temperature +20~500℃ Temperature controller: PID microcomputer control timer: temperature to time; Time to cut off the heating current this machine is equipped with 400℃ oven for choice


The inner liner of the high temperature box is made of stainless steel mirror plate (or wire drawing plate) by argon arc welding. The outer liner of the box is sprayed with high-quality steel plate, which is beautiful and novel. The hot air circulation system is composed of fans and special air ducts that can run continuously at high temperature, and the temperature in the working room is uniform. Independent temperature limit alarm system, exceeding the limit temperature will be interrupted automatically, to ensure the safe operation of the experiment without accidents. A large area of toughened glass observation window is provided for observing the condition of the studio.

Climatic Environmental Test Chambers High Temperature Chamber High-Performance DHG-9030A 101A-0S Test Machine 4

product description:

model DHG-9030A
101A-0S		 DHG-9070A
101A-1S		 DHG-9140A
101A-2S		 DHG-9240A
101A-3S		 DHG-9420A
101A-4S
volume 30L 70L 136L 220L 420L
W*D*H Interior dimension 350*350*350 450*350*450 550*450*550 600*500*750 640*585*1355

W*D*H

carton size

 480*470*685 580*470*785 680*590*885 730*640*1085 780*750*1880
 temperature fluctuation ±1℃ ±1℃ ±1℃ ±1℃ ±1℃
 temperature resolution 0.1℃ 0.1℃ 0.1℃ 0.1℃ 0.1℃
 temperature control range RT+10-250℃ RT+10-250℃ RT+10-250℃ RT+10-250℃ RT+10-200℃
 mains input 220V 50HZ 220V 50HZ 220V 50HZ 220V 50HZ 220V 50HZ
 input powe 650W 1500W 2000W 2400W 4000W
 volume 30L 70L 136L 220L 420L



Our Company:

Climatic Environmental Test Chambers High Temperature Chamber High-Performance DHG-9030A 101A-0S Test Machine 5

Climatic Environmental Test Chambers High Temperature Chamber High-Performance DHG-9030A 101A-0S Test Machine 6



Climatic Environmental Test Chambers High Temperature Chamber High-Performance DHG-9030A 101A-0S Test Machine 7

Climatic Environmental Test Chambers High Temperature Chamber High-Performance DHG-9030A 101A-0S Test Machine 8



Packing/Shipping:

Climatic Environmental Test Chambers High Temperature Chamber High-Performance DHG-9030A 101A-0S Test Machine 9

Climatic Environmental Test Chambers High Temperature Chamber High-Performance DHG-9030A 101A-0S Test Machine 10



Climatic Environmental Test Chambers High Temperature Chamber High-Performance DHG-9030A 101A-0S Test Machine 11

FAQ
1. Do you offer after-sales service? How can I ask for that? And how about the warranty?
Every machine from our factory has a 14-month warranty after shipment. Generally, we offer 12 months for the FREE
maintenance,while considering of sea transportation, we can extend 2 months for our customers.
If your machine doesn’t work, you can send E-mail to us and we will try our best to find the problem by email or sky video chat if necessary. After confirmation of the problem, we can send you new spare parts or provide on-site repair.
2. What’s the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 15-20 working days after
deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
3. Do you accept customization service? Can I have my logo on the machine?
Yes, of course. We can not only offer standard machines, but also customized machines according to your requirements. And we can also put your logo on the machine.
4. How to install and use the product?
We will send you operating instructions, English video by Email. Or you can download on our officail website directly.
Most of our machine is shipped with a whole part, which means it is already installed, all you need to do is to connect the power cable and start to use. And if possible, we can also install your machine at site.
