Manufacturer Lab Drying Oven GB/T2423.1-2006 Programmable High Temperature Chamber Climatic Chamber

Basic Information
Place of Origin: China
Brand Name: BOTO
Certification: MIL STD GB JIS JEDEC IEC ISO
Model Number: B-T-225(A~E)
Minimum Order Quantity: 1PCS
Price: Discussible
Packaging Details: wooden case
Delivery Time: 15days
Payment Terms: T/T, Western Union, L/C
Supply Ability: 1000PC/Month
Model: B-T-225(A~E) Internal Dim: 45x60x45
Name: Programmable High Temperature Chamber Interior: SUS#304Stainless Steel Plate
Exterior: Coating Or SUS#304Stainless Steel Plate Temp Fluctudtiont: ±0.5℃
External Dim: 90X177X130 Temp Uniformity: ±1.0℃
Heat-up Time: About3~5℃/min

Manufacturer Lab Drying Oven GB/T2423.1-2006 Programmable High Temperature Chamber Climatic Chamber



Describe purpose

This test chamber provides high temperature, low temperature, high humidity, low humidity simulation environment, to test the rubber, plastic, electronic products before and after the test material and strength reduction degree.The machine can also simulate the container environment to detect the fading and shrinkage of rubber and plastic under high temperature and humidity.Test heat, cold, dry and moisture resistance of various materials.Suitable for electronic, electrical, batteries, universities, research institutes, inspection and quarantine bureau, paper products, food, vehicles, auto parts, metal, chemical, building materials and other industries factory unit quality control testing.



Manufacturer Lab Drying Oven GB/T2423.1-2006 Programmable High Temperature Chamber Climatic Chamber 0

Manufacturer Lab Drying Oven GB/T2423.1-2006 Programmable High Temperature Chamber Climatic Chamber 1

Corresponding standard:

1. International Electrotechnical Commission Standard:

IEC68-2-03_test method Ca_Steady damp-heat

IEC68-2-01_test method A_cold

IEC68-2-02_test method B_dry heat

2. Military Standards:

MIL-STD-810F-507.4 humidity

MIL-STD-810F-501.4 high temperature

MIL-STD-810F-502.4 low temperature

MIL-STD883C test method 1004.2 temperature and humidity cycling test

MIL-STD810D test method 502.2

MIL-STD810 test method 507.2 procedure 3

3. Japanese Industrial Standard:

JIS C60068-2-3-1987 test method Ca: Steady damp-heat

JIS C60068-2-2-1995 test method B:dry heat

JIS C60068-2-1-1995 test method A:low temperature

4. USA Semiconductor Industry Standard:

JESD22-A101-B-2004 Constant temperature and humidity test

JESD22-A103-C-2004 High Temperature Storage Test

JESD22-A119-2004 Low Temperature Storage Test

Model B-T-120 B-T-225 B-T-504 B-T-1000
(A~D) (A~D) (A~D) (A~D)
Inside size WxHxD (cm) 45x60x45 60x75x50 70x90x80 100x100x100
Humidity deviation ± 2.5% RH
Temperature range -70 degree ~ +100(150) degree
(A:-40 degree B:-50 degree C:-60 degree D:-70 degree)
Humidity range 20%~98%R.H.
Temperature fluctuations ± 0.5 ℃
Temperature deviation ± 2.0 ℃
Heating / cooling time About 3.0/min(heat), about 1.0/min(cool)
Inside material SUS#304Stainless steel plate
Insulation material High-temperature high-density amino acid ethyl ester foam insulation materials,
Program capacity (touch type)
1. Program: 10 groups maximum
2. Number of segments: up to 120 segments
3. Number of cycles: maximum infinite loop
Protection 1. Fault alarming, showing the reason of fault and how to solve the problem
2. Power failure protection function
3. Upper and lower temperature protection function
4. Calendar timing function (automatic start and automatic stop operation)
5. Self-diagnosis function
Power 220VAC±10%       50/60Hz  &  380VAC±10%      50/60Hz
Company Information

Shanghai BOTO GROUP LTD is a high technology company specializing in integrated incubation systems. We are conveniently located in Shanghai City.

With 20+ years of incubator R&D experience from our technical team, we have developed several series of the advanced integrated hatchery system.

Also we have gained the Authorized Poultry Industry R&D Center and been awarded the High-tech Enterprise by Chinese government. Also, both our company and products are approved by ISO9001, ISO14001, ISO45001.

Manufacturer Lab Drying Oven GB/T2423.1-2006 Programmable High Temperature Chamber Climatic Chamber 2

Manufacturer Lab Drying Oven GB/T2423.1-2006 Programmable High Temperature Chamber Climatic Chamber 3

Manufacturer Lab Drying Oven GB/T2423.1-2006 Programmable High Temperature Chamber Climatic Chamber 4



Shipping&Packing



Manufacturer Lab Drying Oven GB/T2423.1-2006 Programmable High Temperature Chamber Climatic Chamber 5

Manufacturer Lab Drying Oven GB/T2423.1-2006 Programmable High Temperature Chamber Climatic Chamber 6

Manufacturer Lab Drying Oven GB/T2423.1-2006 Programmable High Temperature Chamber Climatic Chamber 7

FAQ

Customer: What about the transportation?

Answer: It depends on your requirement. We can delivery by air to your airport, or by sea to your seaport, and we can also delivery to your office address by express courier, and we also accept to co-operate with your ship agent or forwarder.



Customer: What about the after-sale service?

Answer: Guarantee period is 12 months, after the warranty, we also provide life-long paid repair or service. Response within 24 hours for any problems. Overseas training, installation is available.



Customer: What about the delivery date?

Answer: Usually we offer 15workdays after order confirmed and payment received, and we can also accept urgent order for prompt shipment.

Our Services

All machine quality guarantee for one year and lift-time technical support for customer. On line response to customers technical problems.and life-time technical support for customer.
