Place of Origin: | china |
---|---|
Brand Name: | Salt spray corrosion test chamber |
Certification: | IESCO |
Model Number: | B-SST-60 |
Minimum Order Quantity: | 1SET |
Price: | Negotiable |
Packaging Details: | Standard Wooden Box |
Delivery Time: | 5-15days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
Supply Ability: | 1000set/month |
Test Method: | ASTM B117 | Spray Pressure: | 0.2Mpa~0.4Mpa |
---|---|---|---|
Test Time: | 48hrs~1000hrs | Test Humidity: | 95%RH |
Chamber Size: | Customized | Spray Nozzle: | 0.3mm~0.8mm |
Control System: | PLC/PC | Safety Protection: | Overload/ Overheating/ Leakage |
Salt Spray Test Chamber is a high-precision salt spray testing equipment, which is widely used in the inspection of metal surface corrosion resistance. It is mainly used for electroplating, coating, anodizing, metal surface oxidation and other surface treatment processes. The salt spray test chamber has the characteristics of high precision, wide range, and easy to operate. It can change the spray pressure from 0.2Mpa to 0.4Mpa, spray volume from 1ml/80cm2/h to 2ml/80cm2/h, test temperature from 35℃ to 55℃, test humidity 95%RH, and spray distance from 30cm to 50cm.
The Salt Spray Test Chamber is equipped with a high-precision temperature and humidity control system. It can accurately control the temperature and humidity in the test chamber, and provide an ideal environment for salt spray test. The salt spray test chamber is equipped with a high-precision digital flow meter to monitor the spray volume at any time. The spray pressure is adjusted by a high-precision pneumatic pressure regulating valve. The Salt Spray Test Chamber is designed with a high quality corrosion-resistant material, which is durable and reliable.
Salt Spray Test Chamber is an ideal testing equipment for testing the corrosion resistance of metal surface. With its high precision, wide range and easy operation, it can provide accurate testing results for customers.
Parameters | Description |
---|---|
Spray Pressure | 0.2Mpa~0.4Mpa |
Control System | PLC/PC |
Spray Nozzle | 0.3mm~0.8mm |
Safety Protection | Overload/ Overheating/ Leakage |
Chamber Size | Customized |
Test Method | ASTM B117 |
Test Standard | ISO 9227 |
Test Area | 0.09m2~2.25m2 |
Spray Distance | 30cm~50cm |
Product Name | Salt Spray Test Chamber |
Salt spray test chamber, also known as Anti-corrosion testing instrument, is made of corrosion resistant polymer material. It is widely used for testing the corrosion resistance of materials. Model B-SST-60 Salt spray test chamber has a test area of 0.09m2~2.25m2 and is equipped with a PLC/PC control system. The humidity inside the chamber can be controlled to 95%RH, which meets the standard of ISO 9227. The spray volume of the test chamber is 1~2ml/80cm2/h.
Salt spray test chamber is designed to test the corrosion of materials, which helps to identify the corrosion resistance of the materials. With its precise control system, it can provide highly accurate and reliable test results. The test chamber is ideal for research institutions, universities, product quality inspection, material suppliers, and other industrial testing fields.
Brand Name: Salt spray corrosion test chamber
Model Number: B-SST-60
Place of Origin: China
Chamber Material: SUS304
Test Temperature: 35℃~55℃
Control System: PLC/PC
Spray Nozzle: 0.3mm~0.8mm
Test Area: 0.09m2~2.25m2
Features: corrosion resistant polymer material, Industrial material corrosion resistance tester, Industrial material corrosion resistance tester
Salt Spray Test Chamber provides technical support and service covering installation, regular maintenance, quality assurance, and other issues that may arise. Our technical staff is available 24/7 to answer any questions you may have. We also provide training, troubleshooting, and on-site inspections to ensure your Salt Spray Test Chamber is running as efficiently as possible.
We are committed to providing the highest quality of support and service before, during, and after the purchase of our Salt Spray Test Chamber. We are available to discuss your needs and provide solutions that are tailored to fit them. Our team is dedicated to helping you find the best solutions for your specific application and budget.
The Salt Spray Test Chamber should be packed in standard export carton with suitable cushioning material. The inner package is composed of bubble wrap and foam board. The cushioning material should fully cover the chamber in order to protect it from vibration or shock during transportation.
The box should be securely taped and sealed with a waterproof membrane. The box should also be labeled with the product name and a brief description. Additionally, a shipping manifest should be included in the package.
The Salt Spray Test Chamber should be shipped via a reputable and reliable shipping company. The buyer should consider the cost, speed, and route of the shipping company before selecting one.
