Automatic Rain Spray Simulation Environmental Test Chamber GB10485-89

Automatic Rain Spray Simulation Environmental Test Chamber GB10485-89

Application:

Rain Spray Testing Instrument
It is design according to the standard of IP6 & UL 1598, (shell protection grade).This machine is widely used in the lamps and electrical and electronic product certification testing institutions and for testing the waterproof of electrical and electronic products of shell protection level.

Feature:

1. Studio equipped with lighting equipment

2. Rain time, interval time, rainfall intensity, regulate and control apart.

The main technical parameters:

IP6 &UL1598, the external structure: a closed chamber

Inside diameter (L×W× H): 1960 x 1960 x 1900mm

Accessories:

• Circulation pump: 1 pc (can be adjusted)
• Digit flow meter: 4pcs ( to record the pressure of 4pcs spray heads)
• Exhaust fan : 2pcs
• Water filter: 1 set
• UL 1598 standard spray head: 3pcs
• Nozzle: IP6 1 pc, IP5 1pc
• Water tank: 1 set
• Fixture: 1 set
• Adjuster(to adjust height of nozzle): 1 fixture
• Chamber (L×W× H): 1.96 * 1.96 *2.25 m
• IP 6 nozzle (water flow rate: 12.5l/min±5%, nozzle diameter: 12.5mm):
• The internal structure (accord with UL 1598):

Structure of EN/ UL Rain test chambers:

1,The outside layer is composed of the high quality stainless steel plate, the inner container is the composed of stainless steel tabula rasa.

2, Large area of visible glass door, easy to observe the test specimens in the testing chamber

3,The button is made of high quality of tank, can be fixed PU activities wheel, it is convenient for user moved.

4, With 270 degree swing pipe and 360 degrees whorl pole water jet device.

5, Adjustable speed samples stage.

Features of EN/ UL Rain test chambers:

• Rotating rain and spray nozzles designed to JIS specifications
• Speed control for the rotating spray nozzles
• Stationary product shelf - A rotating shelf is optional: see options
• Water pressure regulators, gauges and flow meters
• Special high-volume floor drain system to rapidly drain water out of the chamber
• Interior chamber size is the smallest possible area using the JIS specified nozzles

Other sizes and capabilities available upon request. Please contact us with your application.

Company profile

BOTO GROUP Ltd. is a private enterprise integrating r&d, production, OEM and sales of scientific and technological equipment manufacturing. Proficient in the production, development and upgrading of various non-standard instruments and automatic instruments. The factory covers an area of 26,666 square meters, headquartered in Shanghai, has several offices in China, the factory annual output of about 2000 sets of equipment. Since the establishment of the company, the company is committed to providing customers with quality products and services, and has been praised by customers.

In the domestic market, we have many end customers, third-party testing institutions, research institutes, leading enterprises in different industries, and some agents. For the overseas market, we hope to find more general agents, distributors and importers to cooperate together.

The factory has the ability to calibrate, and the customer can also designate a third party organization to calibrate and issue a calibration report.
