| Place of Origin: | China |
|---|---|
| Brand Name: | BOTO |
| Certification: | CE ISO |
| Model Number: | B-T-48L(A-D) |
| Minimum Order Quantity: | 1set |
| Price: | Negotiation |
| Packaging Details: | PLY-Wooden case |
| Delivery Time: | 20-25work days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 2000set/month |
| Model: | B-T-48(A-D) | Inner Box Size: | 40X40X30cm |
|---|---|---|---|
| External Dimension Size: | 60x80x107cm | Temperature Range: | -60~+150°C（100°C）（A:0°C B:-20°C C:-40°C D:-60°C) |
| Temperature Rise Rate: | 3°C/min | Humidity Range: | 20%-98%RH |
| Cooling Rate: | 0.7-1°C/min | Temperature Deviation: | ±1°C |
| Temperature Fluctuation: | ±0.5°C | Temperature Uniformity: | ±1°C |
Product details
Design Standard: GB/T2423/5170/10586, JIS C60068, ASTM D4714, CNS3625/12565/12566
Uses:
This equipment can simulate different environment condition. It's appropriate for testing material performance,
such as resist heat, resist dry, resist humidity and resist cold. That can define performance of material.
Character:
1. Use the high precision microcomputer touch temperature and humidity controller with high stability of platinum resistance to temperature and wind speed in the circulatory system of temperature and humidity test.
2. Control temperature&humidity well-distributed, precisely and steady.
3. Completely independent system separate for testing in high temperature, low temperature and constant temperature&humidity environment.
Features:
1. Small size, special design and overlapping, not occupying planar space, suitable for laboratory use.
2. Low power consumption, energy saving and consumption reduction; low noise, low radiation, green environmental protection.
3. High efficiency, communication mode using Qualcomm software F4 controller to complete a variety of tests at the same time.
4. Both sides are equipped with side tests. Holes, easy to operate.
5. Multiple safety protection, refrigerant high voltage protection, compressor overload protection, current overload protection, overtemperature protection, leakage protection.
Product details
| Model | B-T-48L(A-D) | B-T-107(A-D) |
| Inner box volume | 48L | |
| Inner box size | 40x40x30cm | 30.5X23X29cm |
| External dimension size | 60x80x107cm | 53X68X72cm |
| Temperature range | -60~+150°C(100°C) (A:0°C B:-20°C C:-40°C D:-60°C) |
-40(-60°C)~+130°C(100°C) (A:0°C B:-20°C C:-40°C D:-60°C) |
| Humidity range | 20$-98%RH | |
| Temperature rise rate | 3°C/min | |
| Cooling rate | 0.7-1°C/min | |
| Temperature deviation | ±1°C | |
| Temperature fluctuation | ±0.5°C | |
| Temperature uniformity | ±1°C | |
*1 Performance values based on IEC60068-3-5:2001 and IEC60068-3-6:2001；Performance data is given at an ambient temperature of +23°C, relative humidity of 65±20%rh, rated voltage and no samples in the test area. *2 when the ambient temperature is + 23 ℃. *3 200V AC is provided with or without NEC specification. *4 Conform to CE mark or UKCA mark. *5 the measurement shall be conducted in an anechoic chamber 1.2m from the floor and 1m from the front panel of the darkroom (ISO 1996-1:2003_a-weighted sound pressure level).
Features:
We have professional packing teams and shipping forwarder to pack and deliver your products!
Packing:
1. Out packing:Standard export wooden case.
2. Inner packing:With careful stretch film wrap product, hard wood board+ strong bandage to fix corners.
3. Checking teams: Specialized staff to inspect and classified your goods.
Shipping:
You can specify other shipping methods such as Airmail, FEDEX or DHL. We shall let you know about the shipping cost after receipt ofyour order.
If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video and English operation muanual. We can provide video-con.
Onsite Service:
1. Device installation 2. Equipment Operation Test Technology training 3. Equipment Calibration 4. Daily maintenance and maintenance of equipment
Free technical training for visiting factories 24-hour Online contact
Free software upgrades
Free information:
1. Product Instruction;2. Product operation instruction/video;3. Experiment Test (test application, test report)
Device Problem Handling:
1. Social media 24 hours online communication;2. Mail Seamless Docking;3. Video Conferencing;4. Artificial free door-to-door service
FAQ
Q1: How can i get a quotation?
A1: Kindly provide us your details request (inner chamber size, temperature range, humidity range, power supply, product, etc.), leave us an inquiry or email and we will response promptly!
Q2: What's your temperature & humidity range?
A1: Our standards temperature range is -70℃~+180℃, 20%~98%RH.
We also can do Ultra low temperature to -190℃ .
Q3: What's your rate of heating & cooling?
A3: Our standards rate is average 3℃/min for heating, 2℃/min for cooling.
3℃/min,5℃/min,8℃/min,10℃/min,15℃/min linear or non-linear speed is available for us.
Q4: What's your warranty?
A4: 12 Months (Noted: free spares parts can be offered during warranty period, exclude consumables and man-made damages), life-time technical service
