| Place of Origin: | China |
|---|---|
| Brand Name: | UV aging test chamber |
| Certification: | ISO CE |
| Model Number: | BT-08 |
| Minimum Order Quantity: | 1 |
| Price: | Negotiable |
| Packaging Details: | Plywood wooden case |
| Delivery Time: | 10-15 |
| Payment Terms: | T/T |
| Supply Ability: | 1000/month |
| Chamber Size: | 550× 1300× 1480mm (D×W×H) | Temperature Uniformity: | ±1℃ |
|---|---|---|---|
| Product Name: | UV Aging Test Chamber | Material: | 304 Stainless Steel |
| Standard Test Piece: | 75×150mm/21 Pieces | UV Wavelength: | 290-400nm |
| Temperature Fluctuation: | ±0.5℃ | Temperature Range: | RT+10℃-70℃ |
| High Light: | Advanced UV Aging Test Equipment,1480mm UV Aging Test Equipment |
||
This UV Test Chamber is designed to provide customers with a reliable and effective UV radiation aging test apparatus, which is used to test the performance of materials exposed to UV radiation. With this UV aging test equipment, customers can have a comprehensive understanding of the UV-induced changes in the properties of the materials. The UV aging test equipment is made of 304 stainless steel and features a temperature fluctuation of ±0.5℃. The UV intensity of this UV aging test equipment ranges from 0.30 to 1.1W/㎡, and the standard test piece is 75×150mm/21 pieces.
| Model | BT-08 UV aging testing machine |
| Temperature range: | RT+10℃～70℃ |
| Temperature fluctuation: | ±0.5℃ |
| Temperature uniformity: | ±1℃ |
| Humidity range: | ≥90%RH |
| Center distance in lamp tube: | 70mm |
| The distance between the test product and the center of the lamp tube: | 50±3mm |
| Ultraviolet tube: | UVA-340 wavelength range 290-400nm (its peak value is 340nm) UVB-313 wavelength range 280-315nm (Its peak is 313nm) |
| Standard test piece: | 75×150mm/21 pieces |
| Irradiation intensity: | 0.30-1.1W/㎡/adjustable 313nm, 340nm band (setting the irradiation intensity value through the touch screen) |
| Irradiation control: | Intelligent control of irradiance, real-time feedback of the irradiance value detected by the irradiance sensor, compared with the set value of the irradiation on the touch, and then the lamp ballast is controlled by the output voltage of the PLC , And finally realize the control of the brightness of the lamp tube, so as to adjust the irradiance PID setting and automatically compensate the set value. |
| Compliant with standards: | GB/T 14522-93 ASTM G 154, ISO 4892-1 ISO 11507 ASTMD 4329 |
We provide technical support and service for UV Test Chamber. Our professional customer service team is available to answer any technical questions you may have about the product. We also offer regular maintenance and calibration services to ensure the accuracy of your product over time. Additionally, we offer on-site installation and training to help you get started quickly and confidently.
Packaging and Shipping for UV Test Chamber:
The UV test chamber is securely packaged in a cardboard box for transit. Then, it is placed in a hardwood crate and strapped with metal bands for additional protection. Finally, we ship the product with a reliable freight carrier.
