| Place of Origin: | China |
|---|---|
| Brand Name: | BOTO |
| Certification: | CE ISO |
| Model Number: | BTHV225-70A |
| Minimum Order Quantity: | 1 set |
| Price: | Negotiable |
| Packaging Details: | wooden |
| Delivery Time: | 15 days |
| Payment Terms: | T/T |
| Supply Ability: | 3000sets/mouth |
| Temperature Range: | -40℃ To +150℃ | Temperature Rising Time: | ≤30min |
|---|---|---|---|
| Temperature Fluctuation: | ≤0.5℃ | Humidity Falling Time: | ≤60min |
| Humidity Range: | 10% To 98% RH | Product Name: | Climatic Test Chamber |
| Humidity Rising Time: | ≤60min | Humidity Uniformity: | ≤3.0%RH |
The Climatic Test Chamber has a voltage requirement of 220V/50Hz, which is a standard power supply in most countries. It has a temperature uniformity of ≤2.0℃, which means that the temperature inside the chamber is evenly distributed, ensuring that the product is subjected to consistent and accurate testing. It also has a humidity uniformity of ≤3.0%RH, which ensures that the humidity inside the chamber is evenly distributed, preventing any localized humidity issues that could affect the accuracy of the test results.
The Climatic Test Chamber is designed to maintain a stable temperature environment with minimal temperature fluctuations. It has a temperature fluctuation of ≤0.5℃, which means that the temperature inside the chamber remains constant, and any temperature changes are within acceptable limits. This ensures that the product is subjected to consistent and accurate testing, and the test results are reliable.
The Climatic Test Chamber is a versatile piece of equipment that can simulate various weather conditions, such as extreme heat, cold, humidity, and dryness. This allows manufacturers to test their products under different climatic conditions, ensuring that the product is suitable for use in different environments. The Climatic Test Chamber can also simulate altitude, rain, snow, and wind, allowing for comprehensive testing of the product's performance and durability.
The Climatic Test Chamber is easy to use, with a user-friendly interface that allows users to set the temperature, humidity, and other test parameters. It is also easy to maintain, with a self-diagnostic system that alerts users to any issues that need attention. The Climatic Test Chamber is made of high-quality materials, ensuring that it is durable and long-lasting.
In conclusion, the Climatic Test Chamber is an essential piece of equipment for manufacturers who need to test their products' durability and performance under different climatic conditions. It is a reliable and efficient tool that can simulate various weather conditions, ensuring that the product is suitable for use in different environments. The Climatic Test Chamber has a voltage requirement of 220V/50Hz, a temperature uniformity of ≤2.0℃, a humidity uniformity of ≤3.0%RH, and a temperature fluctuation of ≤0.5℃. It is easy to use, easy to maintain, and made of high-quality materials, ensuring that it is durable and long-lasting.
The Temperature Humidity Chamber is ideal for testing products that are likely to be exposed to different climatic conditions. The chamber can simulate different weather conditions that include extreme temperatures, high humidity, and even rain. The temperature range of the chamber is from -20°C to 150°C, and the humidity range is from 10% to 98% RH. The humidity rising time is less than or equal to 60 minutes, while the temperature falling and rising time is less than or equal to 30 minutes. The humidity fluctuation is less than or equal to 2.0%RH.
The Weather Simulation Chamber is commonly used in various industries, including automotive, aerospace, electronics, and pharmaceuticals. The chamber is designed to test the durability and reliability of products under different weather conditions. The Temperature Humidity Cycling Chamber is also used to test the aging and corrosion resistance of products. The chamber can also be used to test the performance of products under extreme weather conditions such as cold, heat, and humidity.
The Climatic Test Chamber is suitable for different product application occasions and scenarios. The chamber is commonly used to test the performance of products such as electronic components, automobile parts, and pharmaceutical products. Electronic components such as microchips and printed circuit boards can be tested for their durability and resistance to different weather conditions. Automobile parts such as engines and transmissions can be tested for their performance under different climatic conditions. Pharmaceutical products can be tested for their stability and shelf life under different temperature and humidity conditions.
The minimum order quantity for these Temperature Humidity Cycling Chambers is 1 set and the price is negotiable. The packaging details include wooden packaging for safe and secure transportation.
The delivery time for the product is 15 days and the payment terms are T/T. BOTO has a supply ability of 3000sets/mouth.
The Temperature Rising Time, Temperature Falling Time, Humidity Rising Time, and Humidity Falling Time are all less than or equal to 30 minutes and 60 minutes respectively. The Temperature Range for the Climate Controlled Test Chamber is -40℃ To +150℃.
SPECIFICATIONS OF TEMPERATURE & HUMIDITY CHAMBER
| Item | Specification |
| Internal dimension (W*D*H) | 600*600*800mm |
| Temperature range | +40~+150℃ |
| Temperature fluctuation | ±0.5℃ |
| Temperature uniformity | 2℃ |
| Humidity range | 20~98%RH (Refer Image below) |
| Humidity fluctuation | ±2.5%RH |
| Humidity uniformity | 3%RH |
| Cooling speed | 1℃/min in average (without loading) |
| Heating speed | 3℃/min in average (without loading) |
| Internal chamber material | SUS#304 stainless steel, mirror finished |
| External chamber material | Stainless steel with paint spray |
| Cooling method | Air-cooled |
| Controller |
Programmable control temperature and humidity Can set different parameter for cyclic test |
| Insulation material | 50mm high density rigid Polyurethane foam |
| Heater | Explosion-proof type SUS#304 stainless steel fins radiator pipe heater |
| Compressor | France Tecumseh compressor |
| Lighting | Heat resistance |
| Temperature sensor | PT-100 dry and wet bulb sensor |
| Observation window | Tempered glass |
| Testing hole | Diameter 50mm, for cable routing |
| Sample tray | SUS#304 stainless steel, 2pcs |
| Safety protection device |
Protection for leakage Over-temperature Compressor overvoltage and overload Heater short circuit Water shortage |
The Climatic Test Chamber is a precision instrument that requires technical support and services to ensure optimal performance. Our team of experts is available to assist with the following:
Whether you need help with troubleshooting, upgrading, or customizing your test chamber, we are here to help. Contact us for more information about our technical support and services.
Product Packaging:
The Climatic Test Chamber will be carefully packed in a wooden crate to ensure safe transportation. The crate will be securely sealed and labeled with the necessary information.
Shipping:
The Climatic Test Chamber will be shipped via air or sea freight, depending on the location and customer requirements. The shipping cost will be calculated based on the destination and delivery time. We will provide the customer with the necessary shipping documents and tracking information once the product has been shipped.
Q: What is the brand name of this climatic test chamber?
A: The brand name of this climatic test chamber is BOTO.
Q: Where is this climatic test chamber manufactured?
A: This climatic test chamber is manufactured in China.
Q: What certifications does this climatic test chamber have?
A: This climatic test chamber is certified with CE and ISO certifications.
Q: What is the minimum order quantity for this climatic test chamber?
A: The minimum order quantity for this climatic test chamber is 1 set.
Q: Is the price of this climatic test chamber negotiable?
A: Yes, the price of this climatic test chamber is negotiable.
Q: What are the packaging details for this climatic test chamber?
A: The packaging details for this climatic test chamber are wooden.
Q: What is the delivery time for this climatic test chamber?
A: The delivery time for this climatic test chamber is 15 days.
Q: What are the payment terms for this climatic test chamber?
A: The payment terms for this climatic test chamber are T/T.
Q: What is the supply ability of this climatic test chamber?
A: The supply ability of this climatic test chamber is 3000 sets per month.
