Test Temperature: | 35℃~55℃ | Test Method: | ASTM B117 |
---|---|---|---|
Spray Nozzle: | 0.3mm~0.8mm | Safety Protection: | Overload/ Overheating/ Leakage |
Test Area: | 0.09m2~2.25m2 | Chamber Material: | SUS304 |
Spray Pressure: | 0.2Mpa~0.4Mpa | Product Name: | Salt Spray Test Chamber |
Highlight: | ASTM B117 Salt Spray Test Chamber,BOTO Salt Spray Test Chamber,SUS304 Salt Spray Test Chamber |
The Salt Spray Test Chamber has a test area of 0.09m2~2.25m2, which can accommodate various sizes of specimens. The chamber size can be customized according to the user's specific requirements. The chamber material is made of SUS304, which is resistant to the corrosive effects of the salt spray solution. The chamber is also designed to be easy to clean and maintain.
The Salt Spray Test Chamber has a spray volume of 1~2ml/80cm2/h, which can be adjusted to meet the requirements of different test standards. The device is equipped with a salt spray mist generator, a temperature controller, a pressure regulator, and a salt solution reservoir. The salt spray mist generator produces a fine mist of salt solution, which is uniformly distributed over the specimens. The temperature controller maintains a constant temperature inside the chamber, which is critical for the accuracy of the test results. The pressure regulator controls the pressure of the compressed air, which is used to atomize the salt solution. The salt solution reservoir stores the salt solution, which is automatically replenished when the level is low.
The Salt Spray Test Chamber is powered by AC:220V 50Hz, which is the standard power source in most countries. The device is easy to operate, and the test cycle can be easily programmed using the control panel. The device is also equipped with safety features such as over-temperature protection, over-pressure protection, and low-level alarm.
The Salt Spray Test Chamber is suitable for testing the corrosion resistance of various materials and coatings, such as metals, alloys, paints, plastics, and ceramics. The test results provide valuable information for product development, quality control, and failure analysis. The device is widely used in industries such as automotive, aerospace, marine, electronics, and construction.
The Salt Spray Test Chamber is designed to simulate the harsh environmental conditions that products may be exposed to. The product is commonly used in the automotive, aerospace, and electronics industries. The Salt Spray Testing Chamber is used to test the corrosion resistance of materials and coatings. The B-SST-120 model has a spray distance of 30cm~50cm and a spray pressure of 0.2Mpa~0.4Mpa. The test humidity is 95%RH. The product is equipped with safety protection features to prevent overload, overheating, and leakage.
The Salt Spray Test Chamber is ideal for testing the durability of products that are exposed to harsh environments. The product is commonly used to test the corrosion resistance of materials and coatings used in the automotive industry. The Salt Spray Testing Chamber is also used to test the corrosion resistance of products used in the aerospace industry. The product is also commonly used to test the corrosion resistance of electronics and electrical components. The Salt Spray Test Chamber is a highly specialized product that is essential for ensuring the durability and reliability of products that are exposed to harsh conditions.
Specifications:
Model | BT-60 | BT-90 | BT-120 | BT-160 | BT-200 |
Inner size (cm) | 60x45x40 | 90x60x50 | 120x100x50 | 160x100x50 | 200x100x50 |
External size(cm) | 107x60x118 | 141x88x128 | 190x130x140 | 230x130x140 | 270x130x140 |
Inside temp | Brine test method(NSS ACSS)35°C±1°C/Corrosion resistance test method (CASS)50°C±1°C |
||||
Brine temp | 35°C±1°C 50°C±1°C | ||||
Test chamber volume | 108L | 270L | 600L | 800L | 1000L |
Brine chamber volume | 15L | 25L | 40L | 40L | 40L |
Compressed air pressure | 1.00±0.01kgf/c㎡ | ||||
Spray volume | 1.0~2.0ml/80cm2/h (Collect at least 16 hours, the average) | ||||
Test room relative humidity | 85%RH or more | ||||
PH | 6.5~7.2 3.0~3.2 | ||||
Spray method |
Programmable spray (including the continuous spray interrupted spray) |
||||
Power | AC220V1Φ10A | AC220V1Φ15A | AC220V1Φ20A | AC220V1Φ20A | AC220V1Φ30A |
The Salt Spray Test Chamber is a high-quality product that requires minimal technical support and services. However, if you encounter any issues or have any questions regarding its usage, our team of experts is available to assist you. We provide the following technical support and services:
We strive to provide excellent customer service and ensure that our Salt Spray Test Chamber meets your expectations. Please do not hesitate to contact us if you require any technical support or services.
