Test Method: | ASTM B117 | Chamber Size: | Customized |
---|---|---|---|
Test Temperature: | 35℃~55℃ | Spray Pressure: | 0.2Mpa~0.4Mpa |
Spray Nozzle: | 0.3mm~0.8mm | Product Name: | Salt Spray Test Chamber |
Test Time: | 48hrs~1000hrs | Spray Distance: | 30cm~50cm |
Highlight: | 0.2Mpa~0.4Mpa Anti corrosion testing instrument,35℃~55℃ Temperature corrosion testing instrument,ASTM B117 Anti Corrosion Testing Instrument |
The Salt Spray Test Chamber comes with a range of safety features to ensure the safe and reliable operation of the equipment. The overload protection system prevents damage to the chamber caused by excessive electrical current, while the overheating protection system prevents the unit from overheating and causing a fire. Additionally, the leakage protection system ensures that any leaks are detected and addressed before they can cause any harm.
The Salt Spray Test Chamber boasts an impressive spray volume of 1~2ml/80cm2/h, making it ideal for testing a variety of materials and coatings. With a test area ranging from 0.09m2~2.25m2, this instrument can accommodate a wide range of sample sizes and shapes, allowing for accurate and reliable testing results.
The Salt Spray Test Chamber operates at a test temperature of 35℃~55℃, providing a consistent and controlled testing environment. This ensures that your test results are accurate and reproducible, allowing you to make informed decisions about the performance of your products.
The Salt Spray Corrosion Test Chamber, also known as the Salt Fog Chamber or Corrosion Test Cabinet, is a reliable and efficient instrument for conducting corrosion resistance testing on various products. This product, Model Number B-SST-120, is manufactured in China and has received both CE and ISO certifications.
The Salt Spray Test Chamber is ideal for use in a variety of industries, including automotive, aerospace, electronics, and coatings. It is suitable for testing the corrosion resistance of products such as metals, paints, plastics, and ceramics. The minimum order quantity for this product is 1 set and the price is negotiable.
The Salt Fog Chamber can be used in a variety of scenarios, including product development, quality control, and research and development. It is an essential tool for ensuring that products are able to withstand harsh environmental conditions. The test time for this product ranges from 48 hours to 1000 hours, and the spray pressure ranges from 0.2Mpa to 0.4Mpa. The spray distance ranges from 30cm to 50cm.
The Salt Spray Corrosion Tester is made of high-quality SUS304 material and has a power source of AC:220V 50Hz. This product is capable of conducting accurate and reliable testing, and has a supply ability of 3000 sets per month. The packaging for this product is wooden and the delivery time is 15 days. Payment terms for this product are T/T.
Brand Name: Salt Spray Corrosion Test Chamber
Model Number: B-SST-120
Place of Origin: China
Certification: CE ISO
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wooden
Delivery Time: 15 days
Payment Terms: T/T
Supply Ability: 3000sets/month
Spray Volume: 1~2ml/80cm2/h
Test Humidity: 95%RH
Test Area: 0.09m2~2.25m2
Test Time: 48hrs~1000hrs
Chamber Material: SUS304
Product Keywords: Salt Spray Testing Chamber, Salt Mist Chamber, Salt Spray Resistance Testing Machine
Specifications:
Model | BT-60 | BT-90 | BT-120 | BT-160 | BT-200 |
Inner size (cm) | 60x45x40 | 90x60x50 | 120x100x50 | 160x100x50 | 200x100x50 |
External size(cm) | 107x60x118 | 141x88x128 | 190x130x140 | 230x130x140 | 270x130x140 |
Inside temp | Brine test method(NSS ACSS)35°C±1°C/Corrosion resistance test method (CASS)50°C±1°C |
||||
Brine temp | 35°C±1°C 50°C±1°C | ||||
Test chamber volume | 108L | 270L | 600L | 800L | 1000L |
Brine chamber volume | 15L | 25L | 40L | 40L | 40L |
Compressed air pressure | 1.00±0.01kgf/c㎡ | ||||
Spray volume | 1.0~2.0ml/80cm2/h (Collect at least 16 hours, the average) | ||||
Test room relative humidity | 85%RH or more | ||||
PH | 6.5~7.2 3.0~3.2 | ||||
Spray method |
Programmable spray (including the continuous spray interrupted spray) |
||||
Power | AC220V1Φ10A | AC220V1Φ15A | AC220V1Φ20A | AC220V1Φ20A | AC220V1Φ30A |
The Salt Spray Test Chamber product is designed to simulate a harsh salt-laden environment to test the corrosion resistance of materials. Our technical support team is available to assist with any questions or concerns related to the installation, operation, and maintenance of the Salt Spray Test Chamber. We also offer a range of services, including calibration, repair, and replacement of parts to ensure the continued accuracy and reliability of the Salt Spray Test Chamber. Contact us for more information on our technical support and services.
Product Packaging:
Shipping:
