| Place of Origin: | China |
|---|---|
| Brand Name: | Salt spray corrosion test chamber |
| Certification: | CE ISO |
| Model Number: | B-SST-160 |
| Minimum Order Quantity: | 1 set |
| Price: | Negotiable |
| Packaging Details: | wooden |
| Delivery Time: | 15 days |
| Payment Terms: | T/T |
| Supply Ability: | 3000sets/mouth |
| Spray Nozzle: | 0.3mm~0.8mm | Power Source: | AC:220V 50Hz |
|---|---|---|---|
| Chamber Size: | Customized | Test Time: | 48hrs~1000hrs |
| Test Method: | ASTM B117 | Spray Distance: | 30cm~50cm |
| Chamber Material: | SUS304 | Test Area: | 0.09m2~2.25m2 |
The Salt Spray Test Chamber operates according to the ASTM B117 test method, which involves spraying a salt solution onto the surface of the test specimen for a specified period. This creates a corrosive environment that accelerates the corrosion process, allowing for a quick assessment of the material's resistance to corrosion. The test results can be used to validate the effectiveness of protective coatings and surface treatments.
The Salt Spray Test Chamber comes equipped with a variety of features designed to ensure the safety and reliability of the testing process. The apparatus is equipped with overload and overheating protection to prevent damage to the equipment and ensure accurate test results. Additionally, the chamber is designed to prevent leakage of the salt solution, which could compromise the testing process.
The Salt Spray Test Chamber has a spray distance of 30cm~50cm, which can be adjusted to meet the specific requirements of the test specimen. The spray nozzle has a diameter range of 0.3mm~0.8mm, which allows for precise control of the spray pattern and ensures consistent results.
In summary, the Salt Spray Test Chamber is a highly effective testing apparatus for evaluating the corrosion resistance of metal materials. It operates according to the ASTM B117 test method, has built-in safety features to prevent equipment damage, and allows for precise control of the spray pattern.
The Salt Spray Test Apparatus is designed to test the corrosion resistance of materials and surface coatings. This chamber follows the test method ASTM B117, and it can perform tests from 48 hours to 1000 hours. The test temperature ranges from 35℃ to 55℃, and the spray pressure ranges from 0.2Mpa to 0.4Mpa. The chamber material is made of SUS304.
This Accelerated Corrosion Test Chamber is suitable for a wide range of applications across various industries. It is ideal for testing the corrosion resistance of materials and surface coatings in the automotive, aerospace, marine, and construction industries. It is also useful for testing the durability and quality of metal parts, electronic components, and other materials that are exposed to harsh environments.
The Salt Spray Test Apparatus is a reliable and accurate tool for evaluating the performance of products in corrosive environments. It is a valuable investment for manufacturers who want to ensure the quality and durability of their products. With its easy-to-use interface and durable construction, this chamber can provide accurate and repeatable test results for years to come.
Brand Name: Salt Spray Corrosion Test Chamber
Model Number: B-SST-120
Place of Origin: China
Certification: CE ISO
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wooden
Delivery Time: 15 days
Payment Terms: T/T
Supply Ability: 3000 sets/month
Safety Protection: Overload/ Overheating/ Leakage
Test Area: 0.09m2~2.25m2
Test Method: ASTM B117
Spray Pressure: 0.2Mpa~0.4Mpa
Test Time: 48hrs~1000hrs
Other keywords: Salt Fog Chamber, Accelerated Corrosion Test Chamber, Salt Mist Chamber
Specifications:
| Model | BT-60 | BT-90 | BT-120 | BT-160 | BT-200 |
| Inner size (cm) | 60x45x40 | 90x60x50 | 120x100x50 | 160x100x50 | 200x100x50 |
| External size(cm) | 107x60x118 | 141x88x128 | 190x130x140 | 230x130x140 | 270x130x140 |
| Inside temp | Brine test method(NSS ACSS)35°C±1°C/Corrosion resistance test method (CASS)50°C±1°C |
||||
| Brine temp | 35°C±1°C 50°C±1°C | ||||
| Test chamber volume | 108L | 270L | 600L | 800L | 1000L |
| Brine chamber volume | 15L | 25L | 40L | 40L | 40L |
| Compressed air pressure | 1.00±0.01kgf/c㎡ | ||||
| Spray volume | 1.0~2.0ml/80cm2/h (Collect at least 16 hours, the average) | ||||
| Test room relative humidity | 85%RH or more | ||||
| PH | 6.5~7.2 3.0~3.2 | ||||
| Spray method |
Programmable spray (including the continuous spray interrupted spray) |
||||
| Power | AC220V1Φ10A | AC220V1Φ15A | AC220V1Φ20A | AC220V1Φ20A | AC220V1Φ30A |
The Salt Spray Test Chamber product is designed to simulate the effects of salt spray and fog on various materials and coatings. Our technical support team is available to assist with any questions or issues related to the installation, operation, and maintenance of the chamber. We offer a range of services including calibration, repair, and replacement of parts. Our team is dedicated to ensuring that your Salt Spray Test Chamber is functioning properly and providing accurate results. Contact us for more information on our technical support and services.
