Product Description:
Precision Environmental Chambers are equipped with state-of-the-art technology to provide accurate and reliable testing results. They are designed to maintain a stable temperature and humidity range for extended periods. The temperature range for these chambers is from -70°C to +150°C, and humidity range is from 10% to 98% RH. The humidity accuracy of these chambers is ±2.5% RH. This makes them ideal for testing products under extreme conditions and predicting their performance in the real world.
Environmental Conditioning Chambers come with a range of accessories to enhance the testing capabilities of the chamber. These accessories include a data logger, chart recorder, humidity generator, and more. The data logger is used to record and store temperature and humidity readings over a period of time. The chart recorder is used to provide a visual representation of the test results. The humidity generator is used to control and adjust the humidity level in the chamber.
The temperature uniformity of these chambers is ±1°C, which ensures that the entire chamber is maintained at the same temperature. This is important for testing products that require consistent temperature throughout the chamber. The chamber is designed to be energy-efficient, which reduces the running cost and provides a greener solution for environmental testing.
In conclusion, Environmental Simulation Chambers, Precision Environmental Chambers, and Environmental Conditioning Chambers are essential tools for testing and conditioning products in various industries. They provide a controlled environment to simulate extreme conditions and evaluate the performance and durability of products. These chambers come with a range of accessories to enhance the testing capabilities and provide accurate and reliable results. The temperature range, humidity range, and humidity accuracy of these chambers make them ideal for testing products under extreme conditions. The temperature uniformity and energy efficiency of these chambers make them a cost-effective solution for environmental testing.
Specifications:
|
Model
|
BT-280
|
BT-2150
|
BT-2225
|
BT-2408
|
BT-2800
|
|
Inner Size
W×H×D(cm)
|
40×50×40
|
50×60×50
|
50×75×60
|
60×85×80
|
100×100×80
|
|
Outside Size
W×H×D(cm)
|
93×155×95
|
100×148×106
|
117×166×91
|
140×176×101
|
170×186×111
|
|
Volume (V)
|
80 L
|
150L
|
225L
|
408L
|
800L
|
|
Temp and Hum Range
|
A:-20°C~150°C B: -40°C~150°C C: -60°C~150°C D: -70°C~150°C
RH20%-98%
|
|
Function
|
Fluctuation
|
±0.5°C ±2.5%RH
|
|
Deviation
|
±0.5°C-±2°C ±3%RH(>75%RH); ±5%RH(≤75%RH)
|
|
Controller
Analytical
Accuracy
|
±0.3°C ±2.5%RH
|
|
Wind Cycling Way
|
Centrifugal fan-broadband type forced air circulation
|
|
Refrigeration Way
|
Single stage compression refrigeration
|
|
Refrigerator
|
French Tecumseh
|
|
Refrigerants
|
R4O4A USA DuPont environmental protection refrigerant(R23+R404)
|
|
Condensing Way
|
Air-cooled or water-cooled
|
|
Water Supplying Way
|
Automatic cycling water supply
|
|
Safety device
|
Non- fuse-switch(compressor overload,
refrigerant high low voltage,
over-humidity and temperature protection,
Protection switch,fuse stoppage warning system
|
Applications:
The Environmental Test Chambers are suitable for a variety of product application occasions and scenarios. They are commonly used in the aerospace, automotive, electronics, and pharmaceutical industries. The chambers are designed to simulate different environmental conditions, including temperature, humidity, and light. The temperature range is -70°C to +150°C, and the humidity range is 10% to 98% RH. The chamber dimensions are customizable, making it suitable for a wide range of products.
The Environmental Conditioning Chambers are ideal for testing the durability and performance of products under extreme conditions. They can be used to test the resistance of materials to high and low temperatures, humidity, and other environmental factors. For example, they can be used to test the performance of automotive components in extreme weather conditions, such as freezing temperatures or high humidity. Environmental Testing Chambers can also be used to test the durability of electronic components, such as circuit boards and microchips, under extreme conditions.
The Environmental Testing Chambers are designed with insulation made of fiberglass, which ensures that the temperature is uniform throughout the chamber. The power range is 2-6.5KW, which provides sufficient heating and cooling capacity to meet different testing requirements. The temperature uniformity is ±1°C, ensuring that the test results are accurate and reliable.
Support and Services:
Our Environmental Test Chambers are designed to provide reliable and accurate temperature and humidity testing for a variety of applications. We offer technical support and services to ensure that our customers' test chambers are working efficiently and effectively. Our services include:
- Installation and commissioning of new test chambers
- Regular maintenance and calibration of existing test chambers
- Repair services for any issues that arise
- Technical support for troubleshooting and optimizing test chamber performance
- Training for operators on proper usage and maintenance of test chambers
Our team of trained technicians and engineers are available to provide support and services to our customers worldwide. Contact us for more information on our Environmental Test Chambers technical support and services.
