Product Description:
Our Environmental Test Chambers offer superior Temperature and Humidity Control, allowing for precise testing and experimentation. With Power ratings of 2 to 6.5KW, our chambers are capable of maintaining the most extreme temperature and humidity conditions with ease.
All of our Environmental Test Chambers are certified to meet the highest standards of quality and safety. Our products are UL, CE, RoHS, and other certified, ensuring compliance with all relevant regulations.
Our Environmental Test Chambers are designed for superior Humidity Uniformity, with a precision of ±3% RH. This ensures accurate and repeatable results, even in the most demanding testing environments.
Whether you're testing new products, conducting research, or performing quality control, our Environmental Test Chambers are the ideal solution for your needs. With their precision temperature and humidity control, durable construction, and advanced features, our chambers offer the ultimate in environmental testing technology.
Specifications
|
Model
|
BT-280
|
BT-2150
|
BT-2225
|
BT-2408
|
BT-2800
|
|
Inner Size
W×H×D(cm)
|
40×50×40
|
50×60×50
|
50×75×60
|
60×85×80
|
100×100×80
|
|
Outside Size
W×H×D(cm)
|
93×155×95
|
100×148×106
|
117×166×91
|
140×176×101
|
170×186×111
|
|
Volume (V)
|
80 L
|
150L
|
225L
|
408L
|
800L
|
|
Temp and Hum Range
|
A:-20°C~150°C B: -40°C~150°C C: -60°C~150°C D: -70°C~150°C
RH20%-98%
|
|
Function
|
Fluctuation
|
±0.5°C ±2.5%RH
|
|
Deviation
|
±0.5°C-±2°C ±3%RH(>75%RH); ±5%RH(≤75%RH)
|
|
Controller
Analytical
Accuracy
|
±0.3°C ±2.5%RH
|
|
Wind Cycling Way
|
Centrifugal fan-broadband type forced air circulation
|
|
Refrigeration Way
|
Single stage compression refrigeration
|
|
Refrigerator
|
French Tecumseh
|
|
Refrigerants
|
R4O4A USA DuPont environmental protection refrigerant(R23+R404)
|
|
Condensing Way
|
Air-cooled or water-cooled
|
|
Water Supplying Way
|
Automatic cycling water supply
|
|
Safety device
|
Non- fuse-switch(compressor overload,
refrigerant high low voltage,
over-humidity and temperature protection,
Protection switch,fuse stoppage warning system
|
Applications:
Temperature and Humidity Chambers are commonly used in the electronics, automotive, aerospace, and pharmaceutical industries. These chambers are designed to simulate a range of environmental conditions to test the performance and durability of various products. The chambers are also ideal for testing products that will be exposed to extreme temperature and humidity conditions in their normal use, such as outdoor products.
The B-TH-120 Environmental Test Chambers are made in China and are certified by CE and ISO. The chambers have a minimum order quantity of 1 set and the price is negotiable. The packaging details include a wooden box and the delivery time is 15 days. The payment terms are T/T and the supply ability is 3000 sets per month.
The internal dimensions of the B-TH-120 chamber are 45x60x45 and the temperature accuracy is ±0.5°C. The chambers are also certified by UL, CE, RoHS, and other certifications. These Temperature and Humidity Control Chambers are customizable and can be designed to meet specific testing requirements.
The Environmental Test Chambers are suitable for a wide range of testing applications, including electronic and electrical components, automotive parts, aerospace components, and pharmaceutical products. The chambers are also ideal for testing the effects of temperature and humidity on materials such as plastics, rubber, and textiles.
Overall, the B-TH-120 Environmental Test Chambers are a reliable and efficient tool for testing the effects of temperature and humidity on various products. With their customizable design and precise temperature and humidity control, these chambers are ideal for a range of testing applications.
