Name: Environmental Programmable Constant Temperature Humidity Chamber Climatic Test Chamber
Brand: BOTO GROUP LTD
SKU: B-T-225
Price: 120000 USD
Availability: InStock

Home > Products > Environmental Test Chambers >

Environmental Programmable Constant Temperature Humidity Chamber Climatic Test Chamber

Environmental Programmable Constant Temperature Humidity Chamber

Climatic Test Chamber

Programmable Constant Temperature Humidity Chamber

Place of Origin:

China

Brand Name:

BOTO

Certification:

CE ISO

Model Number:

B-T-225

Request A Quote

Environmental Programmable Constant Temperature Humidity Chamber Climatic Test Chamber

Product Details

Inner Box Size W*H*D（cm）:

50*75*60

Carton Size W*H*D（cm）:

107*161*117

Inner Box Volume:

225L

Temperature And Humidity Control Range:

A:-20℃~150℃ B：-40℃~150℃ C:-60℃~150℃ D: -70℃~150℃ (Special Temperature And Humidity Specifications Can Be Customized)

Temperature And Humidity Fluctuation:

±0.5℃；±2.5%RH

Temperature And Humidity Deviation:

±0.5℃-±2℃；±3%RH（>75%RH）; ±5%RH(≤75%RH)

Controller Resolution:

±0.3℃；±2.5%RH

Controller Brand:

Programmable Korea TEMI880 Touch Screen Controller

Inner Wall:

SUS304#steel Plate

Outer Wall:

SUS304#steel Plate Mist Treatment

Thermal Insulation Material:

High Temperature Resistant High Density Ethyl Chloroformate Foam Insulating Material

System Air Circulation Mode:

Centrifugal Fan-broadband Forced Air Circulation

Cooling Mode:

Single Stage Mechanical Compression System

Refrigerating Machine:

Fully Enclosed Piston French Taikang Compressor

Refrigerant:

R404A Or American DuPont Environmental Refrigerant (R23+R404)

Condensation Method:

Air-cooled

Heater:

Ni-Cr Wire Heater

Humidifier:

Semi-closed Steam Humidification

Water Supply Mode:

Automatic Circulating Water Supply

Power:

220V AC±10% 50HZ

Highlight:

Environmental Programmable Constant Temperature Humidity Chamber

Climatic Test Chamber

Programmable Constant Temperature Humidity Chamber

Payment & Shipping Terms

Minimum Order Quantity

1set

Packaging Details

wooden case

Delivery Time

5-25 days

Payment Terms

L/C, T/T

Supply Ability

30 Set/Sets per Day

Product Description

Environmental Programmable Constant Temperature Humidity Chamber Climatic Test Chamber

Product parameters

Product Name	Constant Temperature and Humidity Test Chamber
Inner box size WHD(cm)	507560
Carton size WHD(cm)	107161117
Inner box volume	225L
Temperature and humidity control range	A:-20℃~150℃ B:-40℃~150℃ C:-60℃~150℃ D: -70℃~150℃ (Special temperature and humidity specifications can be customized)
Temperature and humidity fluctuation	±0.5℃；±2.5%RH
Temperature and humidity deviation	±0.5℃-±2℃；±3%RH(>75%RH); ±5%RH(≤75%RH)
Controller resolution	±0.3℃；±2.5%RH
Controller Brand	Programmable Korea TEMI880 touch screen controller
Inner wall	SUS304#steel plate
Outer wall	SUS304#steel plate mist treatment
Thermal insulation material	High temperature resistant high density ethyl chloroformate foam insulating material
System air circulation mode	Centrifugal fan-broadband forced air circulation
Cooling mode	Single stage mechanical compression system
Refrigerating machine	Fully enclosed piston French Taikang compressor
Refrigerant	R404A or American DuPont environmental refrigerant (R23+R404)
Condensation method	Air-cooled
Heater	Ni-Cr wire heater
Humidifier	Semi-closed steam humidification
Water supply mode	Automatic circulating water supply
Safety device	No fuse switch,( compressor overload, refrigerant high and low pressure, ultra-humidity and over-temperature) protection switch, fuse failure warning system)
Power	220V AC±10% 50HZ

Environmental Programmable Constant Temperature Humidity Chamber Climatic Test Chamber 0

Company introduction

Environmental Programmable Constant Temperature Humidity Chamber Climatic Test Chamber 2

Production line machine

Environmental Programmable Constant Temperature Humidity Chamber Climatic Test Chamber 3

Certifications

Environmental Programmable Constant Temperature Humidity Chamber Climatic Test Chamber 5

Cooperative partners

Environmental Programmable Constant Temperature Humidity Chamber Climatic Test Chamber 7
