Name: BT-DWC-60 Impact Test Chamber for Metal Material with Constant Temperature Cooling
Brand: BOTO GROUP LTD
SKU: BT-DWC-60
Price: 1,750.00 USD
Availability: InStock

Home > Products > Environmental Test Chambers >

BT-DWC-60 Impact Test Chamber for Metal Material with Constant Temperature Cooling

Impact test chamber for metal

Constant temperature cooling test chamber

Environmental test chamber with warranty

Place of Origin:

China

Brand Name:

BOTO

Certification:

CE ISO

Model Number:

BT-DWC-60

Request A Quote

Product Details

Product Name::

Low Temperature Cooling Chamber

Power Supply::

380V 50Hz

Power::

Electronic

Highlight:

Impact test chamber for metal

Constant temperature cooling test chamber

Environmental test chamber with warranty

Payment & Shipping Terms

Minimum Order Quantity

1set

Price

1700-1800 USD

Packaging Details

WOODEN CASE

Delivery Time

5-25DAYS

Payment Terms

L/C, T/T, Western Union

Supply Ability

500 Set/Sets per Month

Automotive Customizable Heat of oil test chamber with Japanese Mitsubishi PLC about 20~260C

Get Best Price

Made-To-Order Comprehensive Temperature,Humidity,Vibration Composite Test Chamber

Get Best Price

B-TH Walk-In High & Low Temperature Alternating Humidity Test Chamber For EV/Energy Storage

Get Best Price

High-Performance Made-To-Order PCT Benchtop High Pressure & High Humidity Environmental Test Chamber

Get Best Price

Contact Now

Product Description

BT-DWC-60 Impact Testing Low Temperature Cooling Chamber

Product Description

1. Application

The machine is designed according to Charpy notch Impact Test Method for Metal Material, and adopts compressor cooling technology. It utilizes the heat balance principle and cycle stirring method to realize the constant temperature cooling to impact specimen with the reliable performance. Digital display, automatic control temperature, and it is the ideal equipment for cooling and keeping temperature to impact specimen.

2. Standards:

ASTM, E23-02a, En10045, ISO83,GB/T229-2009

3. Main Specifications:

Model	BT-DWC-40	BT-DWC-60	BT-DWC-80		BT-DWC-100
Temperature range	+30~-40°	+30~-60°	+30~-80°		+30~-100°
Temperature Control Accuracy	±0.5°
Temperature dropping speed	+30°C~0°C 1.2°C/min	+30°C~0°C 2°C/min	+30°C~0°C 2°C/min	+30°C~0°C 2°C/min
	0°c~-20°C 0.8°C/min	0°c~-20°C 1.5°C/min	0°c~-20°C 1.5°C/min	0°c~-20°C 1.5°C/min
	-20°C~-40°C 0.5°C/min	-20°C~-40°C 1.0°C/min	-20°C~-60°C 1.0°C/min	-20°C~-40°C 1.0°C/min
		-40°C~-60°C 0.7°C/min	-60°C~-80°C 0.7°C/min	-60°C~-100°C 0.7°C/min
Cold Room Volume	150×505×240mm
Dimensions	900×505×850 mm	900×505×850 mm	900×505×850 mm	1500×1200×1200 mm
Box Material	Steel Spray
Loading the number of samples	>60	>60	>60	>200
Mode of refrigeration	Compressor refrigeration
Cooling Medium	Ethanol or other unfrozen liquid
Power	7Kw	7Kw	7Kw	7Kw
