Xenon Lamp Weather Resistance Testing Chamber Aging Test Chamber
|
Product Name
|
Xenon Lamp Test Chamber
|
|
Dimensions of the working chamber D*W*H
|
950×950×850 mm
|
|
Boundary dimension D*W*H
|
1350×1400×2100mm
|
|
Power
|
About 15KW;380V±10% 50HZ
|
|
Temperature range
|
0℃～80℃(Not within the measurement range)
|
|
Temperature deviation
|
±2℃(without the lighting on)
|
|
Humidity range
|
30～98％R.H
|
|
Humidity deviation
|
±2.5%R.H(humidity≥75%R.H) ±3%R.H(humidity≤75%R.H)(without the lighting on)
|
|
The type of light source
|
Water-cooled full solar spectral long arc xenon lamp (average service life of about 1200 hours)
|
|
Rainfall time
|
1 to 9999 minutes, adjustable
|
|
Rainfall cycle
|
1～240 minutes, adjustable interval
|
|
Spectral wavelength
|
290nm～1200nm
|
|
Xenon lamp power
|
1CW, 6KW (lifetime: 1600 hours)
|
|
Wavelength range of light source
|
290-1200nm
|
|
Irradiated area
|
About 7500cm²
|
|
Distance from arc center to sample holder
|
350～380mm
|
|
Rotating speed of sample rotating basket
|
≥1r/min(stepless speed regulation)
|
|
Illumination time
|
Continuous programmable control
|
|
Blackboard temperature
|
65 ℃ + 3 ℃ adjustable
|
|
Refrigeration mode
|
Mechanical refrigeration air-cooled or water-cooled
|
Company introduction
BOTO GROUP is a professional manufacturer of various kinds of testing equipment over 20 years. BOTO products are widely used in paper products, packaging, ink printing, adhesive tapes, bags, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, and applicable to all scientific research units, quality inspection institutions and academic fields.
BOTO deals with customers from more than 150 countries and regions. Meanwhile, we are committed to cooperate with different dealers in different countries and regions in order to offer better service. Our mission is to help every customers establish testing labs to ensure the quality of their products.
Our company will continue to develop, innovate and keep faith. We combine with the international testing standards and the specific demands of customers that may establish a new banner in Chinese testing industry.
Main market
The factory has the ability to calibrate, and the customer can also designate a third party organization to calibrate and issue a calibration report.
Production Process
Production Details
Factory Inspection
We control quality from the materials, electronic parts, controller,comppressor, solenoid valve, and many parts of the products.
Certification
Cooperative partners
BOTO ADVANTAGE
Customers photos
Our Services
During the whole business process, we offer Consultative Selling service.
1) Customer inquiry process:
Discussing testing requirements and technical details, suggested suitable products to customer to confirm. Then quote most suitable price according to customer requirements.
2) Specifications customize process:
Drawing related drawings to confirm with customer for customized requirements. Offer reference photos to show the products appearance. Then, confirm the final solution and confirm final price with customer.
3) Production and delivery process:
We will produce the machines according to confirmed PO requirements. Offering photos to show production process.
After finish production, offer photos to customer to confirm again with the machine. Then do own factory calibration or third party calibration(as customer requirements). Check and test all the details and then arrange packing.
Deliver the products in confirmed shipping time and inform customer.
4) Installation and after sale service:
Defines installing those products in the field and providing after-sales support.
