Walk In Environmental Chamber Temperature Humidity Test Chamber With Large Volume

Walk In Environmental Chamber Temperature Humidity Test Chamber With Large Volume
Walk In Environmental Chamber Temperature Humidity Test Chamber With Large Volume
Walk In Environmental Chamber Temperature Humidity Test Chamber With Large Volume Walk In Environmental Chamber Temperature Humidity Test Chamber With Large Volume
Basic Information
Place of Origin: China
Brand Name: BOTO
Certification: CE ISO
Model Number: BT-XA
Minimum Order Quantity: 1set
Price: Negotiated
Packaging Details: wooden case
Delivery Time: 1-25 days,to be negotiated
Payment Terms: T/T
Supply Ability: 60 Set/Sets per Quarter
Contact Now
Standard:: IEC60068-2-1;IEC60068-2-2;IEC60068 Materials:: SUS304 Stainless Steel
Power Supply:: AC380V 50HZ Temperature Range:: -20℃ To +150℃
Power:: Electronic Useful Volume:: Customized
Cooling Rate:: 1 ℃ / Min Certification:: CE, RoHs
Highlight:

Large Volume Walk In Environmental Chamber

,

Large Volume Test Chamber

,

Temperature Humidity Walk In Environmental Chamber

Walk in Environmental Chamber Temperature Humidity Test Chamber Customization Chamber



Product Description



Walk In Environmental Chamber
BOTO Industry designs and manufactures walk in chambers. These walk-in chambers are in piece assembling structure, which enables on-site installation and commissioning. With large volume, the chamber can be used to simulate the single or complicated environmental factors in the atmosphere such as temperature, humidity, salt fog, illumination, dust, rain and vibration.


Application



Walk in Environmental Chamber Temperature Humidity Test Chamber can be used to analyze and evaluate the property and performance of the batch elements and parts or machine sets under simulated conditions, and can also be used in experiment and production.



Specifications
Product Name
Walk in Environmental Chamber Temperature Humidity Test Chamber
Model
Walk-Ins
Internal dimension (mm)
As request
Overall dimension (mm)
As request
Temperature range
A: -20℃ ～+150 ℃
B:-40℃ ～+150 ℃
C:-70℃ ～+150 ℃
Humidity range
20% ~ 98% RH
Temperature fluctuations
± 0.5 ℃
Temperature deviation
± 2.0 ℃
Humidity deviation
± 2.5% RH
Heating rate
3 ℃ / min
Cooling rate
1 ℃ / min
Temperature Sensor
PTR Platinum Resistance PT100Ω/MV A-class
Temperature Resolution
± 0.001 ℃
Humidity sensor
Dry and wet bulb sensor
Power Supply
AC220V 50HZ
Environmental conditional
5℃~+40 ℃ ≤85% RH



Details


Walk In Environmental Chamber Temperature Humidity Test Chamber With Large Volume 0

Controller

■WiFi connection ■Mobile APP control ■Multi-language controller interface:Russian, French, Polish, Romanian, German
Walk In Environmental Chamber Temperature Humidity Test Chamber With Large Volume 1

Sensor

■Capacitive Temperature And Humidity Sensor ■VAISALA ■ROTRONIC
Walk In Environmental Chamber Temperature Humidity Test Chamber With Large Volume 2

Water Re-circulation

Water purifier: mainly purification from water source to water tank. Water re-circulation system that reduced water use and a series of water pipes
Walk In Environmental Chamber Temperature Humidity Test Chamber With Large Volume 3
Walk In Environmental Chamber Temperature Humidity Test Chamber With Large Volume 4
Walk In Environmental Chamber Temperature Humidity Test Chamber With Large Volume 5

Custom-Made


Walk In Environmental Chamber Temperature Humidity Test Chamber With Large Volume 6

Colour

Appearance colors can be customized
Walk In Environmental Chamber Temperature Humidity Test Chamber With Large Volume 7

Size

Customize according to sample size
Walk In Environmental Chamber Temperature Humidity Test Chamber With Large Volume 8

LIB Walk in chamber

All test chambers support customization
