State Of The Art Environmental Test Chambers For Temperature And Humidity Testing

State Of The Art Environmental Test Chambers For Temperature And Humidity Testing
State Of The Art Environmental Test Chambers For Temperature And Humidity Testing
State Of The Art Environmental Test Chambers For Temperature And Humidity Testing State Of The Art Environmental Test Chambers For Temperature And Humidity Testing
Basic Information
Place of Origin: China
Brand Name: BOTO
Certification: CE ISO
Model Number: BT-YYE009
Minimum Order Quantity: 1set
Packaging Details: wooden case
Delivery Time: 5-25 days
Payment Terms: L/C, T/T
Supply Ability: 100 Set/Sets per Month
Contact Now
Inner Size: 500MM*600MM*500MM (W* H* D) Temperature Range: -20℃~+150℃,adjustable
Temperature Uniformity: ≤±0.5 ℃ Humidity Degree: 10% - 98% R.H
Power: Electronic Outer Size: 1130MM*1750MM*1220MM (W* H* D)
Temperature Fluctuation Degree: ≤±1.0 ℃ Temperature Resolution Accuracy: ±0 .01℃
Humidity Fluctuations Degree: ±2.0%R.H
Highlight:

Temperature Environmental Test Chambers

,

Humidity Environmental Test Chambers

,

Temperature And Humidity Testing environmental chamber

Constant Temperature and Humidity Test Chamber





Cabinet material
Studio
#304 mirror stainless steel (1.2mm)
Outer box
Electrostatic spraying of cold rolled steel plate (1.5mm)
Keep warm
Polyurethane + glass fiber (110mm below -50°C)
Control
German original temperature control instrument (optional with photo), Simple operation, convenient setting, control accuracy0.01℃,
Heater
Fin type stainless steel heating system
Evaporator
Heat exchanger
Note
Customizable



Product Description
State Of The Art Environmental Test Chambers For Temperature And Humidity Testing 0
State Of The Art Environmental Test Chambers For Temperature And Humidity Testing 1
State Of The Art Environmental Test Chambers For Temperature And Humidity Testing 2
Product feature display
State Of The Art Environmental Test Chambers For Temperature And Humidity Testing 3
State Of The Art Environmental Test Chambers For Temperature And Humidity Testing 4
State Of The Art Environmental Test Chambers For Temperature And Humidity Testing 5
Part of the application industry
State Of The Art Environmental Test Chambers For Temperature And Humidity Testing 6
Product Paramenters
State Of The Art Environmental Test Chambers For Temperature And Humidity Testing 7

State Of The Art Environmental Test Chambers For Temperature And Humidity Testing 8
Serial number
Volume
Inner size
D*W*H
Temperature range
Humidity range
Power 50hz/total rate (to be determined)
01
80L
400x400x 500
00~150°C
20~150°C
-40~150°C
- 50~150°C
-60~150°C
- 70~ 150°C
Selected according to test requirements


30~ 98%
220V/5 KW
02
100L
400x500x 500
220V/6KW
03
150L
500x500x 600
220V/6.5KW
04
225L
600x 500x750
220V/7KW
05
408L
800x 600x850
220V/7.5KW
06
800L
1000x800x1000
220V/7.5KW
07
1000L
1000x1000x1000
220V/8KW
Main indicators
a Temperature fluctuation: ≤±0.5°C, temperature uniformity: ≤+2°C
b Humidity error: ≤+2%/-3%R.H
c Cooling rate: 0.7~1°C/min, heating rate: 2~3°C/min
d Temperature change test chamber: cooling 3~5°C/min, heating 3~5/min
e Noise (dB)≤65 (all above are no-load)
Packaging & Transportation
State Of The Art Environmental Test Chambers For Temperature And Humidity Testing 9

Company introduction



State Of The Art Environmental Test Chambers For Temperature And Humidity Testing 10



State Of The Art Environmental Test Chambers For Temperature And Humidity Testing 11State Of The Art Environmental Test Chambers For Temperature And Humidity Testing 12



State Of The Art Environmental Test Chambers For Temperature And Humidity Testing 13
