VOC Environmental Test Chamber Test Facility

VOC Environmental Test Chamber Test Facility
VOC Environmental Test Chamber Test Facility VOC Environmental Test Chamber Test Facility
Basic Information
Place of Origin: China
Brand Name: BOTO
Certification: CE ISO
Model Number: B-VOC
Minimum Order Quantity: 1set
Price: negotiate
Packaging Details: wooden case
Delivery Time: 15*25days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 800 set/year
Contact Now
Volume: 50-1000L,±2% Temperature Range: 15~70℃，±1℃
Temperature Uniformity: ±1℃ Air Exchange Rate: 0.2-2
Air Velocity: 0.1-0.3m/s Formaldehyde Background: ≤0.006 Mg/m³
Greater Than 0.5um: ≤100 Particles/m³ TVOC: ≤0.02 Mg/m³
Toluene Recovery: ≥80% Airleakage Flow Rate: At 1kPa Positive Pressure, The Air Leakage Rate VL ≤ Cabin Capacity ×10-3 Cubic /min
Noise Level: <65dB Voltage Source: 380V，50HZ
Highlight:

VOC Test Facility environmental chamber

,

VOC Environmental Test Chamber

,

Environmental Test Chamber Test Facility

VOC Environmental Test Chamber



Features
1. Cabin material: the outer bulkhead adopts thickened color steel plate, the inner tank adopts SUS304 mirror stainless steel, and the insulation system adopts polyurethane insulation material.
2. Air supply system: it is composed of oil-free air pump, dehumidifier, flow controller, etc. The air pump adopts imported air pump with stable quality.
3. Air filtration system: mainly including VOC, formaldehyde filter and particulate membrane filter. High filtration efficiency, convenient replacement and low cost.
4. Humidity control system: the humidity adopts dry and wet mixed humidity control technology. PLC intelligent control, high precision and low energy consumption.
5. Temperature control system: the overall temperature control adopts the air jacket thermal radiation control mode.



Use :
For the detection of VOCs (volatile organic compounds) release from furniture, carpets, toys, automotive interiors, musical instruments, plastic surfaces of outdoor sports venues and their raw materials
Standards compliant:
T/310101002-C03-2016,HJ 571-2010,
GB 18583-2008,GB18584,
ASTM D5116-97,ISO 16000-9-2006 ,
ANSI/BIFMA X7.1-2007,ENV 13419-1
