Security Protection:
a. The imported high temperature resistant sealed solenoid valve adopts a double circuit structure to ensure no pressure leakage.
b. The whole machine is equipped with multiple pressure protection devices such as over-pressure protection, over-temperature protection, one-button pressure relief, and manual pressure relief to ensure the user's use and safety to the greatest extent.
c. Back pressure door lock device, when there is pressure in the test chamber, the test chamber door cannot be opened
Main Accessories Table:
Thermostat: Touch controller
Test temperature record U disk export (standard configuration)
Computer online control (optional)
High temperature and high pressure water level device: Taiwan Hongyu
High temperature solenoid valve: German herion
Relay: Japan Omron
Pressure Gauge: China Red Flag
Over temperature protector: Korea AGO
Temperature and humidity sensor: VAISALA, Netherlands
Heater: self-produced (all titanium tube)
Pressure safety device: self-produced (copper spring type)
High pressure clean water pump: (Germany) PUM
Hose: Nissan Aseptic
Cabinet material (inner barrel): SUS316
Outer box material: SUS304
Sealing ring: Silicone V-shaped mold
Features:
1. Adopting dual-circuit structure of imported high temperature-resistant solenoid valve, which reduces the failure rate to the greatest extent.
2. Independent steam generation chamber, avoid direct impact of steam on the product, so as not to cause partial damage to the product.
3. The labor-saving structure of the door lock solves the shortcomings of the disc-type handle of the first generation product which is difficult to lock.
4.Exhaust the cold air before the test; the design of the exhausted cold air (exhaust air in the test barrel) during the test improves the pressure stability and reproducibility.
5. Ultra-long-term experiment running time, long-term experiment machine running for 1000 hours.
6. Water level protection, detection and protection through water level sensor in the test room.
7.tank pressure resistance design, the pressure resistance of the cabinet (140 ℃) is 2.65kg, which meets the water pressure test of 6kg.
8. Two-stage pressure safety protection device adopts two-stage combination controller and mechanical pressure protection device.
9. Safety protection pressure release button, two-stage automatic pressure release button of emergency safety device
10. Full touch controller, support U disk export history
