Characteristics:

1. The furnace mantle adopts unique design of double-deck structure with High quality cold-rolled steel plate, The paint is baked at high temperature, it can be used for a long time.

2. Equipped with air-cooling system, the furnace has the advantages of balanced temperature field, low surface temperature, fast temperature rise and fall rate, etc.

3. The vacuum system adopts special design, the vacuum degree is -0.1MPa, and the atmosphere furnace pressure is 0.04MPa, automatic over-pressure and manual exhaust function, make it safe and reliable to use.

4.The inner box adopts integral seal, valve control are equipped with intake valve, exhaust valve, vacuum valve, it can be filled with nitrogen, argon and other inert gas.

5.The imported ceramic alumina poly-crystalline mullite fiber material in furnace is constructed by special technology, which is more energy efficient than traditional electric furnace.

6.The control system adopts the technology of artificial intelligence of microcomputer, which has the functions of PID regulation, fuzzy control, self-tuning, 50 segment programming, and it can program all kinds of programs of temperature rising, constant temperature, cooling temperature, and high precision of temperature control.

7. Modularized thyristor crystal control, phase shift trigger; The heating element is made by imported high quality silicon molybdenum rod.

8. The protection device adopts independent over temperature protection, overcurrent, leakage, short circuit protectio
